Collection: UPS

Eaton 91PS10-10-SN24 is an online double conversion UPS for single phase input and single phase output sites needing longer internal runtime at the full 10kW frame rating. This tall frame configuration includes an internal maintenance bypass switch (MBS) and a network management card for monitoring and alerts.

• Rating: 10kVA / 10kW (unity power factor)
• Topology: online double conversion, VFI class
• Runtime (0.8 pf, per configuration): 24 minutes
• Battery configuration (per schedule): 64 x 34W internal battery
• Comms: network/SNMP standard, 2 x MiniSlot bays

Included: Internal MBS, network card fitted. Installation: hardwired, electrician required.

Eaton 91PS10-10-SN10 is an online double conversion UPS for single phase input and single phase output sites needing high real power capacity and stable output for critical loads. This configuration includes an internal maintenance bypass switch (MBS) and a network management card for monitoring and alerts.

• Rating: 10kVA / 10kW (unity power factor)
• Topology: online double conversion, VFI class
• Runtime (0.8 pf, per configuration): 10 minutes
• Battery configuration (per schedule): 32 x 34W internal battery
• Comms: network/SNMP standard, 2 x MiniSlot bays

Included: Internal MBS, network card fitted. Installation: hardwired, electrician required.

Eaton 91PS8-10-SU32 is an online double conversion UPS for single phase input and single phase output sites needing longer internal runtime. This tall frame configuration includes an internal maintenance bypass switch (MBS) and a network management card for monitoring and alerts.

• Rating: 8kVA / 8kW (unity power factor)
• Topology: online double conversion, VFI class
• Runtime (0.8 pf, per configuration): 32 minutes
• Battery configuration (per schedule): 64 x 34W internal battery
• Comms: network/SNMP standard, 2 x MiniSlot bays

Included: Internal MBS, network card fitted. Installation: hardwired, electrician required.

Eaton 91PS8-10-SU13 is an online double conversion UPS for single phase input and single phase output sites needing clean, stable power for critical loads. This configuration includes an internal maintenance bypass switch (MBS) and a network management card for monitoring and alerts.

• Rating: 8kVA / 8kW (unity power factor)
• Topology: online double conversion, VFI class
• Runtime (0.8 pf, per configuration): 13 minutes
• Battery configuration (per schedule): 32 x 34W internal battery
• Comms: network/SNMP standard, 2 x MiniSlot bays

Included: Internal MBS, network card fitted. Installation: hardwired, electrician required.

Eaton 9SX6KI-AUCC is a high-performance, online double-conversion UPS for 240V single-phase sites that need clean, stable power for critical loads. It continuously regulates voltage and frequency and delivers 6kVA / 5400W output capacity for servers, storage, comms rooms and edge infrastructure.

• Online double conversion (VFI) for consistent output, even with poor mains power
• 240V single-phase design with separate bypass input support
• High efficiency for reduced energy and cooling overheads
• Hot-swappable batteries and internal bypass for service continuity
• Conformally coated variant for improved protection in harsh environments

Important: This AUCC variant is supplied as hardwired input and hardwired output. Installation should be performed by a qualified electrician. Runtime depends on load and whether external battery modules are added.

Eaton Tripp Lite SmartPro SMX1200XLHGL is a 230V, medical-grade, line-interactive tower UPS built for patient-care environments. It provides battery backup, automatic voltage regulation (AVR) and full isolation to help protect sensitive medical equipment from blackouts, brownouts and surges.

• Capacity: 1000VA / 750W
• Battery: long-life lithium iron phosphate (LiFePO4)
• Outlets: 6 x IEC C13 hospital-grade outlets (battery backup + surge protection)
• Full isolation: built-in isolation transformer with Faraday shield helps remove common-mode noise
• AVR: corrects low and high voltage without draining the battery
• Monitoring: USB + DB9 serial for monitoring and unattended shutdown via PowerAlert

Designed for quiet clinical areas, the front-panel LEDs and alarm reporting provide clear status for line power, battery operation, overload and fault conditions.

SMX700HGL is a 230V, medical-grade line-interactive UPS designed for use in medical facilities, including patient care vicinities, when connected to an appropriate hospital-grade outlet. It provides reliable battery backup, automatic voltage regulation (AVR) and full isolation for sensitive equipment.

Unlike traditional UPS models that use sealed lead-acid batteries, the SMX700HGL uses a replaceable lithium iron phosphate (LiFePO4) battery designed for very high cycle life. AVR corrects brownouts and overvoltages without consuming battery, and the built-in isolation transformer with Faraday shield helps remove common mode noise while maintaining surge suppression.

• Capacity: 700VA / 450W
• Battery: LiFePO4 (lithium iron phosphate), replaceable cartridge
• Outlets: 6 x IEC C13 hospital-grade outlets (battery backup + surge protection)
• Isolation: built-in isolation transformer with Faraday shield (full isolation)
• Monitoring: USB + DB9 serial, supports unattended shutdown with PowerAlert
• Voltage correction: AVR input range 155V to 274V

Note: This model does not support external runtime expansion packs. Use runtime figures as a guide only, actual runtime varies based on load and conditions.

The Eaton Tripp Lite SMX1200XLHG is a medical-grade, line-interactive UPS designed for dependable backup power in patient-care vicinities when plugged into a hospital-grade outlet. It provides 1kVA / 750W capacity with full isolation via an integrated isolation transformer and Faraday shield, helping reduce common mode noise while maintaining surge protection in all modes.

Automatic voltage regulation (AVR) corrects brownouts and overvoltages without using battery, keeping connected equipment running through unstable mains power. A quiet alarm mode, clear front-panel status LEDs, and USB/DB9 monitoring with PowerAlert software support safe, unattended shutdown during extended outages.

Need more runtime? This model supports external battery packs for extended runtime, making it suitable for longer power interruptions where you need extra time to ride through or shut down cleanly.
