• APC SMV750CAI Easy UPS 750VA tower back view with digital display
1 1

APC

APC SMV750CAI | Easy UPS SMV 750VA/525W Tower UPS, 6x C13, LCD

APC SMV750CAI | Easy UPS SMV 750VA/525W Tower UPS, 6x C13, LCD

Authorised APC Partner

SMV750CAI

In stock:22

$421.25 inc. GST
$382.95 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The APC Easy UPS SMV750CAI is a 750VA/525W single-phase line-interactive tower UPS that provides battery backup and surge protection for PCs, workstations and small office electronics. It delivers a sine wave output on battery through six IEC C13 outlets, with Automatic Voltage Regulation (AVR) to correct low and high mains voltages without draining the battery, and an LCD display for operating status and alarms.

The tower design is slim enough to be used upright, flat or wall-mounted, and the transformer-block spaced outlets keep neighbouring outlets accessible. A USB and serial port, a dry contact and a free intelligent card slot (network card optional) allow monitoring and integration, while the internal lead-acid battery is included and replaceable.

Features

- Sine wave output on battery for compatibility with active PFC servers and sensitive electronics
- Automatic Voltage Regulation (AVR) corrects low or high voltages without discharging the battery
- Boost AVR preserves battery life and maximises runtime
- LCD graphics display shows operating modes, system parameters and alarms
- Cold-start capable, providing temporary battery power when utility power is out
- Audible alarms and LED indicators for power and UPS status
- Transformer-block spaced outlets leave neighbouring outlets accessible
- Slim design that can be used upright, flat or wall-mounted
- Intelligent card slot and dry contact for monitoring integration (network card optional)
- Replacement battery available

Warranty

APC by Schneider Electric provides comprehensive warranty coverage for its UPS and power protection products. Warranty durations vary by product line and model:
• Back-UPS Series: Typically includes a 3-year warranty.
• Smart-UPS Series: Generally offers a 2 to 3-year warranty, depending on the specific model.
• SMT/SMX Models: Often come with a 3-year warranty on the UPS unit and a 2-year warranty on the battery.
Extended Warranty Options:
IP Trading offers extended warranty solutions for APC products, providing additional peace of mind beyond the standard warranty period. These extensions may include benefits such as:
• 24/7 technical support
• Free shipping on replacement parts
• Replacement of non-functioning batteries
For more details on extended warranty options and to tailor a solution to your needs, please contact the IP Trading team.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

Datasheet

Manual

FAQs

APC Replacement Battery Finder

Technical Specifications

- 750VA / 525W rated power
- Line-interactive topology with sine wave output on battery
- 230V AC single-phase input and output
- Input voltage limits: 165 to 290 V
- 6 x IEC 60320 C13 outlets (battery backup)
- IEC 60320 C14 input connection
- Automatic Voltage Regulation (AVR)
- LCD display
- USB and serial ports
- 1 x Smart/Intelligent Card Slot and dry contact
- Transfer time: 2-6 ms typical, 12 ms maximum
- Surge energy rating: 190 J
- Maximum runtime: 15 min at 50% load, 10 min at 70% load, 6 min at 100% load
- Internal lead-acid battery included
- Tower form factor, 220 x 160 x 410 mm (H x W x D), 13.6 kg

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

FAQs

Q: What topology and output waveform does the SMV750CAI use?
A: It is a line-interactive UPS with a sine wave output on battery, which suits active PFC power supplies and sensitive electronics.

Q: How many outlets does it have and what type are they?
A: It has six IEC 60320 C13 outlets, all with battery backup. Input is via an IEC 60320 C14 inlet.

Q: What load can it support?
A: It is rated for 750VA / 525W. Keep the total connected load within 525W.

Q: How long will it run on battery?
A: Maximum runtime is approximately 15 minutes at 50% load, 10 minutes at 70% load and 6 minutes at full load.

Q: Can I add network management to this UPS?
A: Yes. It has one free Smart/Intelligent Card Slot for an optional network card, plus a dry contact, USB and serial ports for monitoring.

Q: Can the battery be replaced?
A: Yes. The internal lead-acid battery is included and a replacement battery is available.
