• Eaton 9E2000IAU 9E Series 2kVA tower UPS with APC display and logo
1 1

Eaton

Eaton 9E2000IAU | 9E 2kVA/1.8kW Online Tower UPS, IEC C14/6x C13, 240V

Eaton 9E2000IAU | 9E 2kVA/1.8kW Online Tower UPS, IEC C14/6x C13, 240V

Authorised Eaton Partner

9E2000IAU

In stock:4

$1,549.16 inc. GST
$1,408.33 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Eaton 9E 2kVA/1.8kW online double-conversion tower UPS provides continuous, clean power for servers, storage and network equipment. This Australian model has a single IEC C14 input and six IEC C13 outlets, with a 240V nominal output and a compact tower chassis suited to server rooms and comms cabinets.

Double-conversion topology constantly regulates voltage and frequency, while an internal bypass maintains service continuity in the event of a UPS fault. Runtime can be extended with up to four optional EBMs, and a communication card slot supports Network-M2, INDGW-M2 or Relay-MS cards for remote monitoring. Compatible with Eaton Intelligent Power Manager and Intelligent Power Protector software, as well as virtualised environments including VMware, Hyper-V, Citrix Xen and Red Hat.

Features

- Online double-conversion topology constantly monitors power conditions and regulates voltage and frequency
- Internal bypass allows service continuity in case of UPS fault
- LCD display for real-time status and measurements
- Compatible with virtualised environments including VMware, Hyper-V, Citrix Xen and Red Hat
- Long backup time with up to 4 optional EBMs
- Wide input voltage range for high availability
- Works with Eaton Intelligent Power Manager and Intelligent Power Protector software
- Optional network card slot for remote monitoring

Warranty

• Standard UPS (with VRLA batteries): 2–3 year warranty
• Lithium-ion UPS (up to 3kVA): 5-year warranty
Extended Warranty Options:
Extended Eaton UPS warranties are available through IP Trading. Contact us to discuss a plan that suits your power protection needs.
https://www.eaton.com/us/en-us/catalog/services/ups-services/understanding-your-eaton-ups-warranty-.html

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Replacement Battery Finder

Technical Specifications

- Rating: 2000 VA / 1.8 kW
- Topology: Online double-conversion
- Form factor: Tower
- Input: 1 x IEC C14 (10A)
- Output: 6 x IEC C13 (10A)
- Nominal input voltage: 230V default (220/230/240V)
- Input voltage range: 176-300 V (100-300 V with derating)
- Input frequency range: 40-70 Hz
- Input power factor: >0.99
- Output voltage: 230 V, sine wave
- Dimensions (H x W x D): 330 x 190 x 399 mm
- Weight: 22.4 kg
- Communication: 1 USB port and 1 RS232 serial port (not usable simultaneously)
- Communication slot: 1 slot for Network-M2, INDGW-M2 or Relay-MS cards
- Extended battery capability: up to 4 optional EBMs
- Internal bypass: Yes
- Compliances: CE Marked, TUV; IEC/EN 62040-1, IEC/EN 62040-2, EAC

FAQs

Q: What connectors does the Eaton 9E2000IAU use?
A: It has one IEC C14 (10A) input and six IEC C13 (10A) outlets. A suitable IEC C13 to C14 or power lead is needed to connect it to the supply.

Q: Can the runtime be extended?
A: Yes. The 9E supports up to four optional Extended Battery Modules (EBMs) to provide longer backup time.

Q: Can I add remote network monitoring?
A: Yes. The UPS has one communication card slot that accepts Network-M2, INDGW-M2 or Relay-MS cards. It also has USB and RS232 ports, which cannot be used at the same time.

Q: What is the difference between a double-conversion UPS and a line-interactive UPS?
A: The 9E is an online double-conversion UPS, which continuously regulates voltage and frequency and isolates the load from mains disturbances. It includes an internal bypass for service continuity in case of a UPS fault.

Q: What input voltage range does it accept?
A: The input voltage range is 176-300 V, extending down to 100 V with derating, and the input frequency range is 40-70 Hz.

Q: Is it compatible with virtualised server environments?
A: Yes. It is compatible with VMware, Hyper-V, Citrix Xen and Red Hat environments and works with Eaton Intelligent Power Manager and Intelligent Power Protector software.
