APC EMUPS50K250QWHS | Easy UPS 3-Phase Modular 50kVA Online UPS, White, Start-up 5x8

Authorised APC Partner

SKU:EMUPS50K250QWHS

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The APC Easy UPS 3-Phase Modular 50kVA Online UPS is a 400V three-phase double-conversion UPS built for small and medium data centres and other business-critical loads. This SKU is the white 50kVA frame, scalable to 250kVA N+1, and includes 1 switch for external batteries along with a 5x8 start-up service.

The modular design uses live-swappable power, static switch and control modules, so capacity and redundancy can be added as load grows. With up to 96% efficiency in double conversion, up to 99% in ECO mode, a 7-inch colour touchscreen and a standalone 42U rack-style cabinet, it suits deployments that pair the UPS with external battery cabinets.

Features

- Modular architecture: one extra power module gives N+1 redundancy with no footprint penalty
- Live-swappable power module, static switch module, control module and display interface
- EcoStruxure connected package
- 1-year Secure NMC subscription included for future firmware updates
- Includes 5x8 start-up service
- Designed for use with external battery cabinets, 1 switch included
- Cost-optimised design for small and medium data centres

Warranty

APC by Schneider Electric provides comprehensive warranty coverage for its UPS and power protection products. Warranty durations vary by product line and model:
• Back-UPS Series: Typically includes a 3-year warranty.
• Smart-UPS Series: Generally offers a 2 to 3-year warranty, depending on the specific model.
• SMT/SMX Models: Often come with a 3-year warranty on the UPS unit and a 2-year warranty on the battery.
Extended Warranty Options:
IP Trading offers extended warranty solutions for APC products, providing additional peace of mind beyond the standard warranty period. These extensions may include benefits such as:
• 24/7 technical support
• Free shipping on replacement parts
• Replacement of non-functioning batteries
For more details on extended warranty options and to tailor a solution to your needs, please contact the IP Trading team.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Nominal power: 50 kW (50 kVA) per frame, scalable to 250 kW N+1 (50/100/150/200/250 kW)
- Topology: online double conversion, VFI-SS-11 (IEC/EN 62040-3)
- Input/output voltage: 380/400/415 V, 3-phase
- Input frequency: 40-70 Hz; output frequency 50/60 Hz
- Input power factor above 0.99 at full load; THDI 3% or less at linear load
- Output power factor 1; load power factor 0.7 leading to 0.7 lagging without derating
- Efficiency: up to 96% in double conversion, up to 99% in ECO mode
- Modular elements: 50 kW/3U power modules, 250 kW/3U static switch module
- Display: 7-inch colour touchscreen
- Cabinet: standalone 42U 19-inch rack-style
- Battery charging power: 5-60% of output power, user-selectable
- Dry contacts: 4 configurable input, 5 configurable output
- Maximum input short-circuit rating: 35 kA (Icc)
- Overload (normal operation): 110% for 60 min, 125% for 10 min, 150% for 1 min
- Top cable entry, optional bottom cable entry cabinet
- Colour: White

FAQs

Q: How far can this UPS be scaled?
A: The system scales from this 50kVA frame up to 250kVA N+1 by adding 50 kW power modules (50/100/150/200/250 kW).

Q: Are batteries included?
A: No. This SKU is designed for use with external battery cabinets and includes 1 switch for external batteries.

Q: What input and output voltage does it support?
A: It supports 380/400/415 V three-phase input and output, with 50/60 Hz output frequency.

Q: Does it include start-up service?
A: Yes. This SKU includes a 5x8 start-up service.

Q: Can power modules be replaced while the UPS is running?
A: Yes. The power module, static switch module, control module and display interface are live-swappable.

Q: How does efficiency compare between operating modes?
A: Efficiency is up to 96% in double-conversion mode and up to 99% in ECO mode.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
