Moxa UPort 2410 | 4-Port RS-232 USB-to-Serial Converter, DB9

Authorised Moxa Partner

SKU:UPort 2410

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa UPort 2410 is a 4-port RS-232 USB-to-serial converter that connects four legacy or new RS-232 devices to a laptop or workstation through a single Hi-Speed USB 2.0 port. Each port uses a DB9 male connector, and the unit connects to the host via a USB Type B port, making it well suited to mobile, instrumentation and point-of-sale applications.

Serial speeds run from 50 bps up to 921.6 kbps, with selectable data bits, stop bits, parity and flow control settings for each port. The converter is powered directly over USB at 5 VDC, so no external power supply is needed, and drivers are provided for Windows and Linux, with driver support for macOS.

Features

- Hi-Speed USB 2.0 for up to 480 Mbps USB data transmission rates
- 921.6 kbps maximum baudrate for fast serial data transmission
- Drivers provided for Windows and Linux
- Driver support for macOS
- Fixed-base COM utility for setting the initial extended COM port number
- LEDs for easy monitoring

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 4 x RS-232 serial ports, DB9 male
- Hi-Speed USB 2.0 (480 Mbps), USB 1.1/2.0 compliant, USB Type B connector
- Baudrate: 50 bps to 921.6 kbps
- Data bits: 5, 6, 7, 8
- Stop bits: 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow control: None, RTS/CTS, XON/XOFF
- RS-232 signals: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- Input: 5 VDC, 240 mA (USB-powered)
- Housing: Polycarbonate (PC)
- Dimensions (W x H x D): 80 x 35 x 185 mm
- Weight: 210 g (product only)
- Operating temperature: 0 to 55 C
- Storage temperature: -20 to 75 C
- Humidity: 5 to 95% (non-condensing)
- EMI: CISPR 32, FCC Part 15B Class B; EMC: EN 55032/24

FAQs

Q: How many serial devices can the UPort 2410 connect?
A: It provides four RS-232 serial ports with DB9 male connectors, so four devices can share a single USB connection to the host computer.

Q: Does the UPort 2410 need an external power supply?
A: No. It is powered over USB at 5 VDC and draws 240 mA.

Q: Which operating systems are supported?
A: Drivers are provided for Windows and Linux, and driver support is available for macOS.

Q: What is the maximum serial baudrate?
A: Each port supports baudrates from 50 bps up to 921.6 kbps.

Q: Which USB standard does it use?
A: It is a Hi-Speed USB 2.0 device with a USB Type B connector, running at up to 480 Mbps and compliant with USB 1.1/2.0.

Q: Which flow control options are supported?
A: Each port supports None, RTS/CTS and XON/XOFF flow control.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
