Moxa UPort-1110 | UPort 1110 USB-to-Serial Converter, 1-Port RS-232, DB9

Authorised Moxa Partner

SKU:UPort 1110

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The UPort 1110 is a compact USB-to-serial converter that adds one RS-232 DB9 male serial port to a laptop or workstation through a USB Type A connection. It suits industrial and IT environments where a computer has no native serial port but still needs to talk to serial devices such as controllers, instruments and network equipment consoles. The 1-port RS-232 interface runs over USB 2.0 at 12 Mbps with baudrates from 50 bps to 921.6 kbps.

The converter is bus powered from the USB port, so no external power supply is needed. Drivers are available for Windows, Linux and macOS, plus Android and Arm-based platforms, and virtual machine environments such as VMware and Parallels are supported. The lightweight ABS and polycarbonate housing makes it easy to carry for field service and commissioning work.

Features

- Connects a serial device to a computer over a single USB port
- Compatible with Windows, Linux, macOS, Android and Arm-based platforms
- Supports virtual machine environments (VMware, Parallels)
- Compact, lightweight ABS + polycarbonate housing
- Powered from the USB port, no external supply needed
- Full set of RS-232 control signals for reliable device communication

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 1 x RS-232 serial port (DB9 male)
- USB 2.0 compatible, USB 1.1/1.0 compliant, USB Type A, 12 Mbps
- Baudrate 50 bps to 921.6 kbps
- Data bits 5, 6, 7, 8; stop bits 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow control: None, RTS/CTS, XON/XOFF
- RS-232 signals: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- Bus powered: 5 VDC, 30 mA
- Housing: ABS + Polycarbonate
- Dimensions 37.5 x 20.5 x 60 mm, weight 65 g
- Operating temperature 0 to 55°C
- Storage temperature -20 to 70°C
- Ambient relative humidity 5 to 95% (non-condensing)
- MTBF 1,949,025 hrs

FAQs

Q: What type of serial port does the UPort 1110 provide?
A: It provides one RS-232 serial port on a DB9 male connector, with TxD, RxD, RTS, CTS, DTR, DSR, DCD and GND signals.

Q: Does the UPort 1110 need an external power supply?
A: No. It is bus powered from the USB port, drawing 5 VDC at 30 mA.

Q: Which operating systems are supported?
A: Drivers are available for Windows, Linux and macOS, plus Android 3.1.x and later, and Arm-based platforms on Windows 11, Linux and macOS.

Q: What baudrates does it support?
A: It supports baudrates from 50 bps to 921.6 kbps, with 5 to 8 data bits, 1, 1.5 or 2 stop bits, and selectable parity and flow control.

Q: Can it be used with virtual machines?
A: Yes. The UPort 1110 supports virtual machine environments including VMware and Parallels.

Q: What USB standard does it use?
A: It uses a USB Type A connector and is USB 2.0 compatible and USB 1.1/1.0 compliant, with a data rate of 12 Mbps.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
