Moxa UPort 1450I-G2 | UPort 1400-G2 USB to 4-Port RS-232/422/485, 2 kV

Authorised Moxa Partner

SKU:UPort 1450I-G2

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa UPort 1450I-G2 is an industrial USB 3.2 Gen 1 to 4-port RS-232/422/485 serial converter with 2 kV isolation protection. It adds four DB9 male serial ports to a PC or embedded host over a single USB Type B connection, and suits industrial automation, machine control and device-monitoring deployments where electrical isolation protects connected equipment. Its metal housing is rated IP20 and it operates from 0 to 60°C.

Each port supports RS-232, RS-422, RS-485-2w and RS-485-4w, with Automatic Data Direction Control for RS-485 and baudrates from 50 bps to 921.6 kbps. A 512-byte FIFO supports reliable throughput. The converter is backward compatible with USB 2.0 and 1.1, and can be powered from the USB bus or an external 12 to 48 VDC adaptor. Drivers cover Windows, Linux, macOS and Android, plus Arm-based platforms.

Features

- SuperSpeed USB 3.2 Gen 1 interface, backward compatible with USB 2.0/1.1
- 2 kV isolation protection on serial ports
- Supports RS-232, RS-422, RS-485-2w and RS-485-4w
- Automatic Data Direction Control (ADDC) for RS-485
- 512-byte FIFO and baudrates up to 921.6 kbps
- Drivers for Windows, Linux, macOS and Android, plus Arm-based platforms and virtual machines
- Powered by USB bus or by an external 12 to 48 VDC adaptor
- Metal housing

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- USB 3.2 Gen 1 (5 Gbps), USB 2.0/1.1 compatible, USB Type B connector
- 4 x RS-232/422/485 serial ports, DB9 male
- 2 kV isolation protection, 0.5 kV surge
- Baudrate 50 bps to 921.6 kbps, supports non-standard baudrates
- 512-byte FIFO
- Parity: None, Even, Odd, Space, Mark
- Data bits 5, 6, 7, 8; stop bits 1, 1.5, 2
- Flow control: RTS/CTS, XON/XOFF
- RS-485 pull high/low resistor: 1 kilo-ohm or 150 kilo-ohms; 120 ohm terminator
- Power: 5 VDC by USB bus or 12 to 48 VDC by external adaptor
- Metal housing, IP20
- Dimensions: 185 x 30 x 90.6 mm, weight 379 g
- Operating temperature 0 to 60°C, storage -40 to 75°C
- Humidity 5 to 95% (non-condensing)
- Certifications: CISPR 32, FCC Part 15B Class A, EN 55032/35, IEC/EN/UL 62368-1, KC, RoHS, CRoHS, WEEE
- MTBF: 1,140,587 hrs (Telcordia SR332)

FAQs

Q: Which serial interfaces does the UPort 1450I-G2 support?
A: Each of the four DB9 male ports supports RS-232, RS-422, RS-485-2w and RS-485-4w.

Q: What does the I in UPort 1450I-G2 mean?
A: It denotes the isolated model, which provides 2 kV isolation protection on the serial ports.

Q: How is the converter powered?
A: It can be powered from the USB bus at 5 VDC or by an external 12 to 48 VDC power adaptor.

Q: Which operating systems are supported?
A: Drivers are available for Windows 11, 10, 8.1, 8 and 7, Windows Server 2008 R2 to 2022, Linux kernel 4.x to 6.x, macOS 10.1x to 13, Android 3.1.x and later, and Arm-based Linux platforms.

Q: Is it compatible with older USB ports?
A: Yes. It uses USB 3.2 Gen 1 but is backward compatible with USB 2.0 and USB 1.1 hosts.

Q: What temperature range does it operate in?
A: The operating temperature range is 0 to 60°C, so it is not intended for extended-temperature environments.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
