Moxa UPort 1410-G2 | USB to 4-Port RS-232 Serial Converter, 0-60°C

Authorised Moxa Partner

SKU:UPort 1410-G2

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The UPort 1410-G2 is an industrial USB to 4-port RS-232 serial converter that connects four serial devices to a single SuperSpeed USB 3.2 Gen 1 port. Four DB9 male serial ports, a 512-byte FIFO and baudrates up to 921.6 kbps make it suited to industrial automation, data acquisition and device management. This 4-port RS-232 model operates across a 0 to 60°C temperature range.

The converter is built in a rugged metal housing and can be powered from the USB bus or an optional external 12 to 48 VDC adaptor. It is backward compatible with USB 2.0 and USB 1.1 hosts, and drivers are available for Windows, Linux, macOS and Android, as well as VMware and Parallels virtual machines.

Features

- Connects up to 4 RS-232 serial devices over a single USB port
- SuperSpeed USB 3.2 Gen 1 with USB 2.0 backward compatibility
- 512-byte FIFO and up to 921.6 kbps baudrate for high-performance serial communication
- Drivers for Windows, Linux, macOS and Android, plus VMware and Parallels virtual machines
- Rugged metal housing for industrial environments
- Powered by USB bus or an external 12 to 48 VDC adaptor

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- USB 3.2 Gen 1 (USB 1.1/2.0 compliant), USB Type B connector
- USB speeds: 5 Gbps, 480 Mbps, 12 Mbps
- 4 x RS-232 serial ports, DB9 male connectors
- Baudrate: 50 bps to 921.6 kbps, supports non-standard baudrates
- 512-byte FIFO
- Parity: None, Even, Odd, Space, Mark
- Data bits: 5, 6, 7, 8; Stop bits: 1, 1.5, 2
- Flow control: RTS/CTS, XON/XOFF
- RS-232 signals: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- Surge protection: 0.5 kV
- Input voltage: 5 VDC by USB bus power or 12 to 48 VDC by external power adaptor
- Input current: 183 mA @ USB 2.0, 370 mA @ USB 3.2, 200 mA @ 12 VDC
- Metal housing, IP20 rating
- Dimensions: 185 x 30 x 90.6 mm, weight 359 g
- Operating temperature: 0 to 60°C; storage temperature: -40 to 75°C
- Humidity: 5 to 95% (non-condensing)
- MTBF: 1,846,458 hrs (Telcordia SR332)

FAQs

Q: How many serial devices can the UPort 1410-G2 connect?
A: It provides four RS-232 DB9 male serial ports, so up to four serial devices can be connected through one USB port on the host.

Q: Does it work with USB 2.0 ports?
A: Yes. It uses SuperSpeed USB 3.2 Gen 1 but is compliant with USB 2.0 and USB 1.1 hosts. Input current is 183 mA on USB 2.0 and 370 mA on USB 3.2.

Q: Which operating systems are supported?
A: Drivers are available for Windows 11, 10, 8.1, 8 and 7, Windows Server 2008 R2 to 2022, Linux kernels 4.x, 5.x and 6.x, macOS 10.1x to 13, and Android 3.1.x and later.

Q: How is the UPort 1410-G2 powered?
A: It can run from 5 VDC USB bus power, or from an optional external power adaptor supplying 12 to 48 VDC.

Q: What is the maximum baudrate?
A: Baudrates from 50 bps up to 921.6 kbps are supported, including non-standard baudrates, with a 512-byte FIFO.

Q: What operating temperature range does this model support?
A: This model operates from 0 to 60°C (32 to 140°F).

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
