Moxa UPort-1150 | UPort 1150 1-Port RS-232/422/485 USB-to-Serial Converter

Authorised Moxa Partner

SKU:UPort 1150

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa UPort 1150 is a 1-port RS-232/422/485 USB-to-serial converter that adds a software-selectable serial port to any computer without a native one. It is the non-isolated model with a USB Type A connector and a compact plastic housing, a practical choice for laptops, instrumentation and point-of-sale deployments where galvanic isolation is not required.

The Hi-Speed USB 2.0 interface is bus-powered, so no external supply is needed, and baudrates up to 921.6 kbps are supported. It ships with a mini DB9F-to-terminal-block adapter for easy wiring, and drivers are provided for Windows, macOS, Linux and WinCE. LEDs show USB and TxD/RxD activity at a glance.

Features

- Hi-Speed USB 2.0 for up to 480 Mbps USB data transmission rates
- 921.6 kbps maximum baudrate for fast serial data transmission
- Software-selectable RS-232, RS-422, 2-wire RS-485 and 4-wire RS-485 (default RS-232)
- Drivers provided for Windows, macOS, Linux and WinCE
- Mini DB9-female-to-terminal-block adapter for easy wiring
- LEDs indicate USB and TxD/RxD activity
- Plug-and-play USB device for mobile, instrumentation and POS applications
- Bus-powered, no external power adapter required

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 1 x RS-232/422/485 serial port (DB9 male)
- USB 2.0 Hi-Speed host interface, USB Type A connector
- USB 1.0/1.1 compliant, USB 2.0 compatible
- Baudrate: 50 bps to 921.6 kbps
- Data bits: 5, 6, 7, 8
- Stop bits: 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow control: None, RTS/CTS, XON/XOFF
- Serial standards: RS-232, RS-422, RS-485 (2-wire and 4-wire)
- Input: 5 VDC, 77 mA, bus-powered
- Housing: ABS + Polycarbonate
- Dimensions: 37.5 x 20.5 x 60 mm
- Weight: 65 g
- Operating temperature: 0 to 55 C
- Storage temperature: -20 to 70 C
- Ambient relative humidity: 5 to 95% (non-condensing)
- MTBF: 1,949,025 hours

FAQs

Q: Is the UPort 1150 isolated?
A: No. The UPort 1150 is the non-isolated model with a plastic housing. Moxa's UPort 1150I is the 2 kV isolated variant.

Q: Which serial interfaces does it support?
A: It supports RS-232, RS-422, 2-wire RS-485 and 4-wire RS-485. The interface is selected in software and defaults to RS-232.

Q: What operating systems are supported?
A: Drivers are provided for Windows, macOS, Linux and WinCE.

Q: Does it need an external power supply?
A: No. It is bus-powered from the USB port, drawing 5 VDC at 77 mA.

Q: What is the maximum serial baudrate?
A: The UPort 1150 supports baudrates from 50 bps up to 921.6 kbps.

Q: What is included for wiring the serial port?
A: A mini DB9F-to-terminal-block adapter is included, making it easy to wire RS-422 and RS-485 connections.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
