Description

The Moxa NPort IA5150I-G2-T is a 1-port industrial RS-232/422/485 serial device server designed for DIN-rail mounting. It connects a serial device to an Ethernet network over two 10/100 RJ45 ports, and delivers 2 kV serial isolation and a -40 to 75°C wide operating temperature range for harsh industrial environments.

As part of the second-generation NPort IA5000-G2 range, it supports Real COM, TCP Server, TCP Client, UDP, Reverse Terminal, RFC2217 and Pair Connection modes, with secure Real COM and secure TCP Server options. Hardware security including Secure Boot and a true random number generator, together with HTTPS, SSHv2 and SNMPv3, helps protect serial-to-Ethernet deployments. Driver support covers Windows 11, Linux and macOS, including Arm-based platforms and virtual machines.

Features

- Secure Boot and root-of-trust hardware security
- Software-selectable RS-232/422/485 interface
- Dual Ethernet ports for daisy-chain topology
- 2 kV serial isolation protects connected equipment
- Wide -40 to 75°C range for harsh industrial environments
- Support for Arm-based platforms and virtual machines

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 1 x RS-232/422/485 serial port, software-selectable, DB9 male
- 2 x 10/100BaseT(X) RJ45 Ethernet ports (switch/daisy-chain)
- 2 kV serial isolation
- Operating temperature: -40 to 75°C
- DIN-rail mounting
- Operation modes: Real COM, TCP Server, TCP Client, UDP, Reverse Terminal, RFC2217, Pair Connection
- Secure modes: Secure Real COM, Secure TCP Server
- Security: HTTPS (TLS 1.2), SNMPv3, SSHv2, Secure Boot, TRNG
- Protocols: ARP, DHCP, DNS, HTTPS, ICMP, IPv4, LLDP, SMTP, SNMPv1/v2c/v3, TCP/IP, UDP, SNTP
- Driver support: Windows 11, Linux kernels 4.x/5.x/6.x, macOS 11-14, fixed TTY drivers

FAQs

Q: Which serial interfaces does the NPort IA5150I-G2-T support?
A: It has one software-selectable RS-232/422/485 serial port on a DB9 male connector.

Q: What does the -T in the model name mean?
A: The -T suffix denotes the wide temperature model, rated for operation from -40 to 75°C.

Q: Can I daisy-chain devices from the two Ethernet ports?
A: Yes. The two 10/100BaseT(X) RJ45 ports operate as a switch, so Ethernet devices can be daisy-chained.

Q: What does the I in IA5150I mean?
A: The I model provides 2 kV serial isolation protection for the serial port.

Q: Which operating systems are supported for COM port mapping?
A: Drivers are available for Windows 11, Linux kernels 4.x, 5.x and 6.x, macOS 11 to 14, and fixed TTY drivers.

Q: How is the unit mounted?
A: It is designed for DIN-rail mounting.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
