• Silver and black Moxa NPort 4120 serial converter with labeled ports
1 1

Moxa

Moxa NPort 6250-T | NPort 6250 2-Port RS-232/422/485 Secure Device Server, -40 to 75°C

Moxa NPort 6250-T | NPort 6250 2-Port RS-232/422/485 Secure Device Server, -40 to 75°C

Authorised Moxa Partner

NPort 6250-T

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The NPort 6250-T is a 2-port RS-232/422/485 secure serial device server that connects serial equipment to an Ethernet network over a single RJ45 10/100BaseT(X) port. Its metal housing and wide -40 to 75°C operating temperature range make it well suited to industrial automation, utilities and harsh-environment deployments where standard terminal servers would fail.

Each DB9 serial port is software-selectable between RS-232, RS-422 and RS-485, with baudrates from 50 bps to 921.6 kbps and support for non-standard baudrates. Secure operation modes including Secure Real COM, Secure TCP Server, Secure TCP Client and SSH, along with HTTPS and SSH configuration, protect serial traffic and remote management. It can be mounted on a desktop, a wall or a DIN-rail (optional kit) and runs from a 12 to 48 VDC supply.

Features

- Secure operation modes for Real COM, TCP Server, TCP Client, Pair Connection, Terminal and Reverse Terminal
- Supports non-standard baudrates with high precision
- Enhanced remote configuration with HTTPS and SSH
- Each serial port supports RS-232, RS-422 and RS-485, selectable from the configuration menu
- Wide-temperature design for -40 to 75°C operation
- Built-in watchdog timer, buzzer and real-time clock

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x RS-232/422/485 serial ports (DB9 male)
- 1 x 10/100BaseT(X) Ethernet port (RJ45, auto MDI/MDI-X)
- Baudrate: 50 bps to 921.6 kbps, non-standard baudrates supported
- Data bits: 5, 6, 7, 8
- Stop bits: 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow control: RTS/CTS, DTR/DSR, XON/XOFF
- RS-485 pull high/low resistors: 1 kilo-ohm, 150 kilo-ohms
- RS-485 data direction control: ADDC (Automatic Data Direction Control)
- RS-485 terminator: 120 ohms
- Secure modes: Reverse SSH, Secure Pair Connection, Secure Real COM, Secure TCP Client, Secure TCP Server, SSH
- SD slot: up to 32 GB (SD 2.0 compatible)
- Input voltage: 12 to 48 VDC
- Metal housing
- Dimensions (with ears): 101 x 111 x 29 mm
- Dimensions (without ears): 77 x 111 x 29 mm
- Weight: 240 g
- Mounting: desktop, wall, DIN-rail (optional kit)
- Operating temperature: -40 to 75°C

FAQs

Q: What serial standards does the NPort 6250-T support?
A: Each of its two DB9 male serial ports supports RS-232, RS-422 and RS-485, selectable from the configuration menu.

Q: What is the operating temperature range?
A: The NPort 6250-T operates from -40 to 75°C, suiting it to industrial and outdoor cabinet installations.

Q: How is serial data secured?
A: It supports Secure Real COM, Secure TCP Server, Secure TCP Client, Secure Pair Connection and SSH operation modes, and device configuration is protected with HTTPS and SSH.

Q: What power input does it require?
A: It accepts 12 to 48 VDC.

Q: Can it be mounted on a DIN-rail?
A: Yes, DIN-rail mounting is supported with an optional kit. Desktop and wall mounting are also supported.

Q: What Ethernet interface does it use?
A: It has one 10/100BaseT(X) RJ45 port with auto MDI/MDI-X.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
