Moxa NPort 6250-S-SC-T | NPort 6250-S 2-Port Secure Serial Device Server, SM SC, -40 to 75C

Moxa NPort 6250-S-SC-T | NPort 6250-S 2-Port Secure Serial Device Server, SM SC, -40 to 75C

Authorised Moxa Partner

NPort 6250-S-SC-T

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Moxa NPort 6250-S-SC-T is a 2-port secure serial device server that connects RS-232/422/485 serial devices to an Ethernet network over a single-mode 100BaseFX SC fibre port. SSL and SSH encryption protects serial data in transit, making it well suited to industrial automation, utilities and transport deployments. The wide-temperature design operates from -40 to 75°C, and this -T model does not include a power adapter.

The two DB9 male serial ports are software-selectable between RS-232, RS-422 and RS-485, with baudrates from 50 bps to 921.6 kbps. Secure Real COM, Secure TCP Server and Client, Secure Pair Connection and Reverse SSH operation modes are supported alongside standard modes such as Real COM, RFC2217 and UDP. A metal housing, 1.5 kV magnetic isolation and an SD card slot for extended port buffering suit it to demanding industrial environments.

Features

- SSL and SSH encryption of serial data over Ethernet
- Secure Real COM, Secure TCP Server, Secure TCP Client, Secure Pair Connection and Reverse SSH modes
- Supports nonstandard baudrates with high precision
- Remote configuration over HTTPS, SSH and Telnet, plus Windows utility
- 64 KB port buffers, expandable via SD card, store serial data when Ethernet is offline
- IPv6 supported
- Authentication via local accounts, RADIUS and TACACS+
- Security features based on IEC 62443
- 3-in-1 serial ports with interface selectable from the configuration menu
- Built-in watchdog timer, buzzer and real-time clock

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x RS-232/422/485 serial ports, DB9 male
- 1 x 100BaseFX single-mode SC fibre port
- Single-mode typical distance 40 km at 1310 nm
- Operating temperature -40 to 75°C (wide temp.)
- Input 12 to 48 VDC, 430 mA
- Power adapter not included
- SD card slot, up to 32 GB (SD 2.0 compatible)
- Baudrate 50 bps to 921.6 kbps
- 1.5 kV built-in magnetic isolation protection
- Metal housing, 240 g
- Dimensions 77 x 111 x 29 mm (89 mm with ears)
- Desktop, wall or DIN-rail mounting (optional kit)
- MTBF 1,526,091 hrs (Telcordia TR/SR)

FAQs

Q: Does the NPort 6250-S-SC-T include a power adapter?
A: No. As a -T wide-temperature model it ships without a power adapter. It runs from a 12 to 48 VDC supply drawing 430 mA.

Q: What Ethernet interface does this model use?
A: It has one 100BaseFX single-mode SC fibre port with a typical reach of 40 km at 1310 nm. It does not have an RJ45 Ethernet port.

Q: Which serial interfaces are supported?
A: Both DB9 male serial ports are selectable between RS-232, RS-422 and RS-485 from the configuration menu.

Q: How is serial data secured?
A: The secure operation modes use SSL and SSH encryption, including Secure Real COM, Secure TCP Server and Client, Secure Pair Connection and Reverse SSH.

Q: What temperature range does it support?
A: The wide-temperature design operates from -40 to 75°C, suiting unconditioned industrial cabinets and outdoor enclosures.

Q: Can it be DIN-rail mounted?
A: Yes, DIN-rail mounting is supported with an optional kit. Desktop and wall mounting are also supported.
