Moxa NPort 6250-S-SC | NPort 6250 Secure Terminal Server, 2-Port, SM SC Fibre

Authorised Moxa Partner

SKU:NPort 6250-S-SC

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa NPort 6250-S-SC is a 2-port RS-232/422/485 secure serial device server with a single-mode 100BaseFX (SC) Ethernet uplink, rated for typical runs of up to 40 km. It carries serial data over Ethernet using TLS and SSH encryption, making it well suited to connecting serial equipment across long fibre links in industrial and infrastructure networks. The 0 to 55 C operating range and metal housing suit controlled cabinet and desktop deployments, and a region-suitable power adapter is included.

Both DB9 serial ports are software selectable between RS-232, RS-422 and RS-485, with baudrates from 50 bps to 921.6 kbps and support for non-standard rates. Secure operation modes include Secure Real COM, Secure TCP Server, Secure TCP Client, Secure Pair Connection, SSH and Reverse SSH, alongside standard modes such as Real COM, TCP Server, UDP, RFC2217 and Terminal. Security features are based on IEC 62443, with HTTPS (TLS 1.2), SSHv2 and SNMPv3 plus RADIUS and TACACS+ authentication.

Features

- Secure operation modes for Real COM, TCP Server, TCP Client, Pair Connection, Terminal and Reverse Terminal
- Single-mode fibre (100BaseFX) uplink for long-distance runs
- 3-in-1 serial ports with RS-232/422/485 selected in software
- Supports non-standard baudrates with high precision
- Enhanced remote configuration over HTTPS and SSH
- Port buffers store serial data while Ethernet is offline
- IPv6 support
- Generic serial commands supported in Command-by-Command mode
- Security features based on IEC 62443
- Built-in 1.5 kV magnetic isolation protection on the Ethernet interface
- Power adapter included

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x RS-232/422/485 serial ports (DB9 male)
- 1 x 100BaseFX single-mode fibre port (SC connector), typical distance 40 km
- Fibre cable type G.652, typical wavelength 1310 nm, link budget 29 dB
- Baudrate 50 bps to 921.6 kbps (supports non-standard baudrates)
- Data bits 5, 6, 7, 8; stop bits 1, 1.5, 2; parity None, Even, Odd, Space, Mark
- Flow control: RTS/CTS, DTR/DSR, XON/XOFF
- SD card slot, up to 32 GB (SD 2.0 compatible)
- Security: HTTPS (TLS 1.2), SSHv2, SNMPv3; RADIUS and TACACS+ authentication
- Input voltage 12 to 48 VDC, 430 mA
- Metal housing, 101 x 111 x 29 mm with ears, 240 g
- Operating temperature 0 to 55 C, storage temperature -40 to 75 C
- Desktop, DIN-rail (optional kit) and wall mounting
- Power adapter included in the box

FAQs

Q: What type of Ethernet connection does the NPort 6250-S-SC use?
A: It has a single 100BaseFX single-mode fibre port with an SC connector, with a typical distance of 40 km at 1310 nm.

Q: Which serial standards does it support?
A: Both DB9 male serial ports support RS-232, RS-422 and RS-485, selected in software.

Q: Which secure operation modes are available?
A: Reverse SSH, Secure Pair Connection, Secure Real COM, Secure TCP Client, Secure TCP Server and SSH.

Q: Is a power adapter included?
A: Yes. A region-suitable power adapter, a quick installation guide and a warranty card are included. The unit accepts 12 to 48 VDC.

Q: What is the operating temperature range?
A: This model operates from 0 to 55 C. It is not a wide-temperature variant.

Q: Can it be DIN-rail mounted?
A: Yes, with the optional DIN-rail kit. Desktop and wall mounting are also supported.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
