Moxa NPort 6250-M-SC-T | 2-Port RS-232/422/485 Secure Device Server, Multi-Mode SC Fibre, -40 to 75°C

Authorised Moxa Partner

SKU:NPort 6250-M-SC-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa NPort 6250-M-SC-T is a 2-port RS-232/422/485 secure terminal server that connects serial devices to Ethernet over a 100BaseFX multi-mode SC fibre port. This wide-temperature model operates from -40 to 75°C, making it suited to factory floors, outdoor cabinets and other harsh industrial sites where fibre isolation and noise immunity matter.

Secure operation modes with remote configuration over HTTPS and SSH let you integrate legacy serial equipment into modern networks. Built-in 1.5 kV magnetic isolation, a 64 KB port buffer expandable via SD card, and flexible authentication through local accounts, RADIUS and TACACS+ support dependable, secure deployments.

Features

- Secure operation modes: Real COM, TCP Server, TCP Client, Pair Connection, Terminal and Reverse Terminal
- Supports nonstandard baudrates with high precision
- Remote configuration over HTTPS and SSH
- Queues serial data in the port buffer during an Ethernet outage and releases it in order once the connection returns
- Port buffer can be expanded with an SD card
- Authentication via local accounts, RADIUS and TACACS+
- Unicast routing with RIPv1/v2 and static routes

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x RS-232/422/485 serial ports (DB9 male)
- 1 x 100BaseFX Ethernet port (multi-mode SC connector)
- 1.5 kV built-in magnetic isolation protection
- Operating temperature -40 to 75°C (wide temperature -T model)
- Input voltage 12 to 48 VDC
- Power consumption 428 mA @ 12 VDC
- Metal housing, 730 g
- SD card slot, up to 32 GB (SD 2.0 compatible)
- Built-in 64 KB port buffer
- Built-in watchdog timer (WDT), buzzer and RTC
- Desktop installation (DIN-rail kit available separately)

FAQs

Q: What type of fibre connection does the NPort 6250-M-SC-T use?
A: It has one 100BaseFX Ethernet port with a multi-mode SC connector, so it connects to multi-mode fibre infrastructure.

Q: What operating temperature range does this model support?
A: The -T model is rated for -40 to 75°C, suitable for harsh industrial environments.

Q: Which serial interfaces are supported?
A: Each of the 2 DB9 male serial ports can be configured for RS-232, RS-422 or RS-485.

Q: How is the device secured and configured remotely?
A: It supports secure operation modes and remote configuration over HTTPS and SSH, with authentication through local accounts, RADIUS and TACACS+.

Q: What happens to serial data if the Ethernet link goes down?
A: Serial data is queued in the 64 KB port buffer and released in order once the connection returns. The buffer can be expanded using an SD card.

Q: What power input does it require and can it be DIN-rail mounted?
A: It accepts 12 to 48 VDC input. It is designed for desktop installation, and a DIN-rail kit is available separately.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
