Moxa NPort 6250-M-SC | NPort 6250 2-Port RS-232/422/485 Secure Device Server, Multi-Mode SC

Moxa NPort 6250-M-SC | NPort 6250 2-Port RS-232/422/485 Secure Device Server, Multi-Mode SC

Authorised Moxa Partner

NPort 6250-M-SC

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Moxa NPort 6250-M-SC is a 2-port RS-232/422/485 secure serial device server that connects serial equipment to a 100BaseFX multi-mode fibre Ethernet network over an SC connector. It supports secure operation modes over SSL and SSH, making it well suited to protecting serial-connected industrial equipment, with a standard operating temperature range of 0 to 55°C.

Each DB9 serial port supports baudrates from 50 bps to 921.6 kbps, including non-standard rates, and the unit is configurable through HTTPS, SSH, Telnet, serial console and Moxa utilities. Built-in 1.5 kV magnetic isolation, a watchdog timer and port buffering for offline Ethernet periods help keep serial data protected and flowing.

Features

- Secure operation modes: Secure Real COM, Secure TCP Server, Secure TCP Client, Secure Pair Connection, Reverse SSH and SSH
- Standard operation modes including Real COM, TCP Server, TCP Client, UDP, RFC2217, Terminal, Reverse Telnet, PPP, Printer and Ethernet Modem
- Remote configuration over HTTPS, SSH, Telnet, serial console, Device Search Utility and MCC Tool
- Security protocols: HTTPS (TLS 1.2), SNMPv3 and SSHv2 with AES-128/256 encryption
- Authentication via local database, RADIUS or TACACS+
- Port buffers store serial data when Ethernet is offline
- IPv4 and IPv6 support
- Automatic Data Direction Control (ADDC) for RS-485
- Built-in watchdog timer, buzzer and real-time clock

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x RS-232/422/485 serial ports (DB9 male)
- 1 x 100BaseFX multi-mode fibre port (SC connector)
- Typical multi-mode fibre distance: 4 km (OM1 50/125 µm), 1300 nm
- Serial baudrate: 50 bps to 921.6 kbps (non-standard baudrates supported)
- Data bits 5, 6, 7, 8; stop bits 1, 1.5, 2; parity None, Even, Odd, Space, Mark
- Flow control: RTS/CTS, DTR/DSR, XON/XOFF
- SD slot up to 32 GB (SD 2.0 compatible)
- Input voltage: 12 to 48 VDC, 430 mA
- 1.5 kV built-in magnetic isolation protection
- Operating temperature: 0 to 55°C (32 to 131°F)
- Storage temperature: -40 to 75°C (-40 to 167°F)
- Ambient relative humidity: 5 to 95% (non-condensing)
- Metal housing, 240 g
- Dimensions (with ears): 101 x 111 x 29 mm
- Dimensions (without ears): 77 x 111 x 29 mm
- Desktop, wall and DIN-rail mounting (DIN-rail with optional kit)
- MTBF: 1,526,091 hrs (Telcordia/Bellcore TR/SR)
- 5-year warranty

FAQs

Q: What network connection does the NPort 6250-M-SC use?
A: It has a single 100BaseFX multi-mode fibre port with an SC connector. The typical distance is 4 km over OM1 50/125 µm fibre at 1300 nm.

Q: Which serial interfaces does it support?
A: Both DB9 male serial ports are software selectable between RS-232, RS-422 and RS-485. Baudrates range from 50 bps to 921.6 kbps, including non-standard rates.

Q: Does it support secure serial communication?
A: Yes. Secure operation modes include Secure Real COM, Secure TCP Server, Secure TCP Client, Secure Pair Connection, Reverse SSH and SSH. Configuration is protected with HTTPS (TLS 1.2), SSHv2 and SNMPv3.

Q: What is the operating temperature range and power requirement?
A: This standard model operates from 0 to 55°C and is powered from 12 to 48 VDC at 430 mA.

Q: How can it be mounted?
A: It can be used on a desktop, wall mounted, or DIN-rail mounted with the optional DIN-rail kit.

Q: Can I use it with a copper Ethernet network instead?
A: This SKU has a multi-mode fibre SC port only. Other NPort 6250 models are available with a 10/100BaseT(X) copper port, so choose the variant that matches your network medium.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
