Moxa NPort 6250-G2-T | 2-Port RS-232/422/485 Secure Terminal Server, -40 to 75°C

Authorised Moxa Partner

SKU:NPort 6250-G2-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa NPort 6250-G2-T is a 2-port RS-232/422/485 secure terminal server that connects serial devices to an Ethernet network. Built for harsh industrial environments, this wide temperature model operates from -40 to 75°C and features a rugged metal housing, 1.5 kV magnetic isolation and a 12 to 48 VDC power input. It suits factory automation, energy, transport and building management deployments where serial equipment needs reliable network access.

As part of the NPort 6000-G2 range, it adds Secure Boot with a hardware root of trust, authentication via local database, RADIUS and TACACS+, and a microSD slot supporting up to 2 TB. Real TTY drivers are available for Windows and Linux, with fixed TTY drivers for macOS, making it straightforward to integrate legacy serial applications into modern IT infrastructure.

Features

- Secure Boot root of trust with True Random Number Generator (TRNG) and security screws
- Authentication via local database, RADIUS and TACACS+
- Real TTY drivers for Windows 11/10/8.1/8/7 and Windows Server 2008 R2 to 2022
- Linux Real TTY drivers for kernel 4.x, 5.x and 6.x
- Fixed TTY drivers for macOS 11 to 14
- Arm-based platform and virtual machine support
- Wide -40 to 75°C operating range for harsh environments

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x RS-232/422/485 serial ports
- 1 x 10/100BaseT(X) Ethernet port (RJ45), auto MDI/MDI-X
- 1.5 kV built-in magnetic isolation protection
- Operating temperature: -40 to 75°C
- Power input: 12 to 48 VDC, 160 mA max
- microSD slot, up to 2 TB
- Software-configurable RS-485 120 ohm terminator and 1 kilo-ohm/150 kilo-ohm pull high/low resistors
- Automatic Data Direction Control (ADDC) for RS-485
- Metal housing
- Dimensions (with ears): 76.3 x 122.4 x 25 mm
- Weight (product only): 278 g
- Built-in WDT, buzzer and RTC

FAQs

Q: How many serial ports does the NPort 6250-G2-T have?
A: It has 2 serial ports, each software-selectable for RS-232, RS-422 or RS-485.

Q: What operating temperature range does this model support?
A: The -T variant operates from -40 to 75°C, suited to unconditioned cabinets and outdoor enclosures.

Q: What power input does the NPort 6250-G2-T require?
A: It accepts a 12 to 48 VDC power input with a maximum draw of 160 mA.

Q: Which operating systems are supported for Real TTY mode?
A: Real TTY drivers are available for Windows 11/10/8.1/8/7, Windows Server 2008 R2 to 2022, and Linux kernels 4.x, 5.x and 6.x. Fixed TTY drivers are available for macOS 11 to 14.

Q: What security features are built in?
A: It includes Secure Boot with a hardware root of trust and TRNG, security screws, and authentication through a local database, RADIUS or TACACS+.

Q: Can I use it with RS-485 devices without external terminators?
A: Yes. The RS-485 120 ohm terminator and pull high/low resistors are software-configurable, and Automatic Data Direction Control (ADDC) is supported.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
