Moxa NPort 6250 | 2-Port RS-232/422/485 Secure Serial Device Server

Authorised Moxa Partner

SKU:NPort 6250

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa NPort 6250 is a 2-port RS-232/422/485 secure serial device server that connects serial equipment to an Ethernet network through a single 10/100BaseT(X) RJ45 port. It supports secure operation modes including Secure Real COM, Secure TCP Server and Client, Secure Pair Connection, SSH and Reverse SSH, so serial data can be encrypted with SSL/SSH when it crosses the network. This standard-temperature model operates from 0 to 55 C and ships with a power adapter.

Two DB9 male serial ports support baudrates from 50 bps to 921.6 kbps, including non-standard baudrates. A metal housing, built-in watchdog timer, buzzer and RTC suit industrial and commercial installations, while an SD slot supports cards up to 32 GB. Management is available through a web console, Telnet/SSH, SNMP and Moxa utilities, with Real COM and TTY drivers for Windows, Linux and macOS.

Features

- Secure operation modes for Real COM, TCP Server, TCP Client, Pair Connection, Terminal and Reverse Terminal
- SSL/SSH encryption of serial data sent over the network
- HTTPS (TLS 1.2), SNMPv3 and SSHv2 security protocols
- Supports non-standard baudrates
- SD card slot for expanded storage
- Real COM and TTY drivers for Windows, Linux and macOS
- Management via web console, Telnet/SSH, SNMP and Windows utility
- Built-in watchdog timer, buzzer and RTC
- NEMA TS2 traffic control certification

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x RS-232/422/485 serial ports (DB9 male)
- 1 x 10/100BaseT(X) Ethernet port (RJ45), auto MDI/MDI-X
- Baudrate 50 bps to 921.6 kbps, supports non-standard baudrates
- Data bits 5, 6, 7, 8; stop bits 1, 1.5, 2
- Flow control RTS/CTS, DTR/DSR, XON/XOFF
- Parity None, Even, Odd, Space, Mark
- SD slot up to 32 GB (SD 2.0 compatible)
- 1.5 kV built-in magnetic isolation protection
- Input voltage 12 to 48 VDC, 430 mA
- Operating temperature 0 to 55 C
- Storage temperature -40 to 75 C
- Ambient relative humidity 5 to 95% (non-condensing)
- Metal housing, 240 g
- Dimensions 101 x 111 x 29 mm (with ears), 77 x 111 x 29 mm (without ears)
- Desktop, DIN-rail (optional kit) and wall mounting
- Package includes terminal server, power adapter, quick installation guide and warranty card

FAQs

Q: What serial interfaces does the NPort 6250 support?
A: It has two DB9 male serial ports, each software-selectable for RS-232, RS-422 or RS-485.

Q: Does the NPort 6250 support encrypted serial data?
A: Yes. Secure operation modes including Secure Real COM, Secure TCP Server, Secure TCP Client, Secure Pair Connection, SSH and Reverse SSH protect serial data with SSL/SSH.

Q: Is a power adapter included?
A: Yes. The package includes a region-specific power adapter, a quick installation guide and a warranty card. The unit accepts 12 to 48 VDC at 430 mA.

Q: What operating temperature range does this model cover?
A: This is the standard-temperature model, rated for 0 to 55 C.

Q: Which operating systems are supported by the drivers?
A: Real COM and TTY drivers are available for Windows, Linux and macOS.

Q: Can the NPort 6250 be DIN-rail mounted?
A: Yes, with the optional DIN-rail kit. It can also be used on a desktop or mounted on a wall.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
