Moxa NPort 5650-8 | NPort 5600 8-Port RS-232/422/485 Rackmount Serial Device Server

Authorised Moxa Partner

SKU:NPort 5650-8

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The NPort 5650-8 is an 8-port RS-232/422/485 rackmount serial device server that connects serial devices to a 10/100 Ethernet network. It provides eight 8-pin RJ45 serial ports and a single RJ45 Ethernet port in a metal 19-inch housing, and runs from a universal 100 to 240 VAC input with an operating range of 0 to 60 C. An LCD panel and push buttons make IP address setup quick without a PC.

Serial ports support baud rates up to 921.6 kbps, with Real COM/TTY drivers for Windows and Linux, fixed TTY drivers for macOS, and socket modes including TCP server, TCP client and UDP. Configuration is available through Telnet, a web browser or a Windows utility, and management support includes SNMP MIB-II, with HTTPS and SNMPv3 for secure access.

Features

- Standard 19-inch rackmount size
- Easy IP address configuration with LCD panel and push buttons
- Configure by Telnet, web browser or Windows utility
- Socket modes: TCP server, TCP client and UDP
- SNMP MIB-II for network management
- Real COM/TTY drivers for Windows and Linux, plus fixed TTY drivers for macOS
- Tx/Rx LEDs per serial port, plus system and Ethernet LEDs, for easier maintenance
- DIP switches for adjustable termination and pull high/low resistors
- Universal 100 to 240 VAC power input
- Built-in watchdog timer for automatic reboot

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 8 x RS-232/422/485 serial ports (8-pin RJ45)
- 1 x 10/100BaseT(X) Ethernet port (RJ45)
- Baud rate: 50 bps to 921.6 kbps
- Data bits 5, 6, 7, 8; stop bits 1, 1.5, 2; parity None, Even, Odd, Space, Mark
- Flow control: None, RTS/CTS, DTR/DSR (RS-232 only), XON/XOFF
- RS-485 pull high/low resistors: 1 kilo-ohm, 150 kilo-ohms; 120 ohm terminator
- Input voltage: 100 to 240 VAC, 47 to 63 Hz
- Input current: 158 mA @ 100 VAC
- Operating temperature: 0 to 60 C (32 to 140 F)
- Metal housing, 19-inch rack mounting
- Dimensions with ears: 482.60 x 43.65 x 198.25 mm
- Weight: 2,430 g
- Magnetic isolation: 1.5 kV built-in; ESD 15 kV air, 8 kV contact
- Operation modes: Real COM, TCP Client, TCP Server, UDP, Ethernet Modem, Pair Connection, Reverse Telnet, RFC2217
- 5-year warranty

FAQs

Q: What serial interfaces does the NPort 5650-8 support?
A: Each of the eight RJ45 serial ports supports RS-232, RS-422 and RS-485, with baud rates from 50 bps up to 921.6 kbps.

Q: How is the NPort 5650-8 powered?
A: It has a built-in universal power supply accepting 100 to 240 VAC at 47 to 63 Hz, and ships with a region-specific power cord.

Q: How do I set the IP address?
A: The front LCD panel and push buttons allow IP setup without a PC. It can also be configured over Telnet, a web console (HTTP/HTTPS) or the Windows utility.

Q: Which operating systems are supported for virtual COM ports?
A: Real COM/TTY drivers are available for Windows and Linux, with fixed TTY drivers for macOS.

Q: Does it support RS-485 termination?
A: Yes. DIP switches enable a 120 ohm terminator and 1 kilo-ohm or 150 kilo-ohm pull high/low resistors, and automatic data direction control handles RS-485 direction.

Q: What is included in the box?
A: The NPort 5650-8 device server, a rack-mounting kit, a region-specific power cord, a quick installation guide and a warranty card.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
