Description

The Moxa NPort 5630-8 is a 19-inch rackmount serial device server that connects 8 RS-422/485 serial devices to a 10/100M Ethernet network. Eight RJ45 serial ports and a 100-240 VAC power input make it a straightforward way to bring multiple legacy serial devices onto an IP network from a single rack unit.

An LCD panel allows quick IP address setup, and the unit can also be configured through a web console, Telnet or the Windows utility. Socket modes include TCP server, TCP client and UDP, and SNMP MIB-II support allows monitoring within existing network management systems.

Features

- Standard 19-inch rackmount size with metal housing
- Easy IP address configuration with LCD panel
- Configure by Telnet, web browser or Windows utility
- Socket modes: TCP server, TCP client, UDP
- SNMP MIB-II for network management
- Supports protocols including DHCP, BOOTP, DNS, SNMP V1, HTTP, SMTP, SNTP, RTelnet and RFC2217

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 8 x RS-422/485 serial ports (8-pin RJ45)
- 1 x 10/100BaseT(X) Ethernet port (RJ45)
- 1.5 kV built-in magnetic isolation protection
- Baudrate: 50 bps to 921.6 kbps
- Data bits: 5, 6, 7, 8
- Stop bits: 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow control: XON/XOFF
- Input voltage: 100 to 240 VAC
- Dimensions (W x H x D): 440 x 45 x 198 mm
- Operating temperature: 0 to 55 C
- MTBF: 844,009 hrs (MIL-HDBK-217F)
- Safety: UL 60950-1
- EMC: EN 55032/24
- Package includes rack-mount kit, power cord, document and software CD, quick installation guide

FAQs

Q: How many serial ports does the NPort 5630-8 have and what standards do they support?
A: It has 8 serial ports using 8-pin RJ45 connectors, supporting RS-422 and RS-485.

Q: What power input does the NPort 5630-8 use?
A: It has a 100 to 240 VAC power input, and a power cord is included in the package.

Q: How is the IP address configured?
A: The IP address can be set using the front LCD panel. The unit can also be configured through a web console, Telnet console or the Windows utility.

Q: Does it come with rackmount hardware?
A: Yes. The package includes a rack-mount kit for standard 19-inch racks.

Q: What operating modes are available for the serial ports?
A: Socket modes include TCP server, TCP client and UDP.

Q: What is the maximum serial baudrate?
A: The baudrate range is 50 bps to 921.6 kbps.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
