Moxa NPort 5610-8 | 8-Port RS-232 Rackmount Device Server, RJ45

Authorised Moxa Partner

SKU:NPort 5610-8

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa NPort 5610-8 is an 8-port RS-232 rackmount serial device server that connects serial devices to an Ethernet network. It uses RJ45 8-pin serial connectors, accepts 100-240 VAC input and fits a standard 19-inch rack, making it well suited to server rooms and equipment cabinets that need centralised serial access.

An LCD panel simplifies IP address setup, and the unit can also be configured over Telnet, a web console or the Windows utility. Operating modes include TCP server, TCP client, UDP and Real COM, with SNMP MIB-II support for network management.

Features

- Standard 19-inch rackmount size
- Easy IP address configuration with LCD panel
- Configuration via Telnet, web console or Windows utility
- SNMP MIB-II for network management
- Drivers support the RTS, CTS, DTR, DSR and DCD control signals

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 8 x RS-232 serial ports with RJ45 8-pin connectors
- 10/100M auto-sensing Ethernet
- Rackmount form factor (standard 19-inch)
- 100-240 VAC power input
- Operating temperature 0 to 60 °C
- Socket modes: TCP server, TCP client, UDP, Real COM

FAQs

Q: How many serial ports does the NPort 5610-8 have?
A: It has 8 RS-232 serial ports, each terminated with an RJ45 8-pin connector.

Q: What power input does the NPort 5610-8 use?
A: It accepts a 100-240 VAC power input.

Q: How is the NPort 5610-8 configured?
A: The IP address can be set using the front LCD panel, and the unit can be configured via Telnet, a web console or the Windows utility.

Q: Which operating modes are supported?
A: The NPort 5610-8 supports TCP server, TCP client, UDP and Real COM modes.

Q: Does it mount in a standard rack?
A: Yes, it is a standard 19-inch rackmount unit.

Q: What network speed does it support?
A: It provides 10/100M auto-sensing Ethernet.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
