Moxa NPort-5450I-T | NPort 5450I-T 4-Port Serial Device Server, 2 kV, -40-75C

Authorised Moxa Partner

SKU:NPort 5450I-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa NPort 5450I-T is a 4-port RS-232/422/485 serial device server that connects legacy serial equipment to a 10/100 Ethernet network. Each DB9 male port supports 2 kV isolation protection, and the wide-temperature -T model operates from -40 to 75°C, making it suited to industrial automation, factory floors and harsh remote cabinets.

Dual 12 to 48 VDC power inputs (removable terminal block and power jack) give flexible, redundant power options, while the metal housing supports desktop, DIN-rail or wall mounting. Each serial port runs in its own operation mode, including Real COM, TCP Server, TCP Client, UDP, Reverse Telnet and Pair Connection, and the unit is configured by Telnet, web browser or Windows utility.

Features

- 2 kV isolation protection on serial ports
- Wide-temperature operation from -40 to 75°C
- Dual DC power inputs via terminal block and power jack
- Independent operation mode for each serial port
- Socket modes: TCP server, TCP client and UDP
- Adjustable termination and pull high/low resistors for RS-485
- Configure by Telnet, web browser or Windows utility
- SNMP MIB-II support for network management
- Metal housing with desktop, DIN-rail and wall mounting options

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 4 x RS-232/422/485 serial ports, DB9 male
- 1 x 10/100BaseT(X) Ethernet port, RJ45
- 2 kV serial isolation protection
- Serial standards: RS-232, RS-422, RS-485
- Data bits: 5, 6, 7, 8; stop bits: 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow control: RTS/CTS and DTR/DSR (RS-232 only), XON/XOFF
- RS-485 pull high/low resistors: 1 kilo-ohm, 150 kilo-ohms; 120 ohm terminator
- RS-485 data direction control: ADDC (automatic)
- Input voltage: 12 to 48 VDC, 2 power inputs
- Input current: 554 mA @ 12 VDC
- Power connectors: removable 3-contact terminal block and power input jack
- Built-in WDT automatic reboot, buzzer and RTC alert tools
- Metal housing; 181 x 103 x 33 mm with ears, 158 x 103 x 33 mm without ears
- Weight: 740 g
- Operating temperature: -40 to 75°C

FAQs

Q: Which serial standards does the NPort 5450I-T support?
A: Its four DB9 male ports each support RS-232, RS-422 and RS-485, selectable per port.

Q: What does the -T suffix mean?
A: The -T model is the wide-temperature version, rated for operation from -40 to 75°C.

Q: Does this model have serial isolation?
A: Yes. The NPort 5450I-T provides 2 kV isolation protection on its serial ports.

Q: Does the -T model have an LCD panel?
A: No. The LCD panel is only fitted to standard temperature models. The -T model is configured by Telnet, web browser or Windows utility.

Q: What power input does it use?
A: It accepts 12 to 48 VDC through two inputs, a removable terminal block and a power jack.

Q: How can it be mounted?
A: The metal housing supports desktop, DIN-rail and wall mounting.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
