• Moxa NPort 5230-T back view with black chassis, green terminals, dual ports
1 1

Moxa

Moxa NPort-5230-T | NPort 5230-T 2-Port Serial Device Server, -40 to 75°C

Moxa NPort-5230-T | NPort 5230-T 2-Port Serial Device Server, -40 to 75°C

Authorised Moxa Partner

NPort 5230-T

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Moxa NPort 5230-T is a 2-port serial device server that connects one RS-232 port and one RS-422/485 port to a 10/100 Ethernet network. It is the -40 to 75°C wide-temperature model with terminal block serial connectors and a 12 to 48 VDC power input, making it suited to industrial cabinets, outdoor enclosures and other harsh environments where serial equipment needs to be network-ready.

Supported operation modes include Real COM, TCP Server, TCP Client, UDP, Pair Connection and Reverse Telnet, with Windows Real COM and Linux Real TTY drivers available. Configuration is via a Windows utility, serial console, Telnet console or web console, and automatic data direction control simplifies RS-485 deployments. The metal housing supports desktop, wall and optional DIN-rail mounting.

Features

- Makes serial devices network-ready, such as card readers and payment terminals
- Operation modes: Real COM, TCP Server, TCP Client, UDP, Pair Connection, Reverse Telnet
- Windows Real COM and Linux Real TTY drivers, fixed TTY drivers for macOS and other UNIX systems, plus an Android API
- Configurable via Windows utility, serial console, Telnet console or web console
- Built-in watchdog timer, buzzer and real-time clock
- Automatic data direction control (ADDC) for RS-485
- Wide -40 to 75°C operating range for harsh industrial environments

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x serial ports: 1 x RS-232 and 1 x RS-422/485
- 1 x 10/100BaseT(X) Ethernet port (RJ45)
- Serial connector: terminal block
- Baudrate: 110 bps to 230.4 kbps
- Data bits: 5, 6, 7, 8; stop bits: 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow control: RTS/CTS and DTR/DSR (RS-232 only), XON/XOFF
- Input voltage: 12 to 48 VDC, 325 mA @ 12 VDC
- Power connector: removable 3-contact terminal block
- Operating temperature: -40 to 75°C
- Magnetic isolation protection: 1.5 kV (built-in)
- Housing: metal
- Dimensions: 90 x 100.4 x 22 mm (with ears), 67 x 100.4 x 22 mm (without ears)
- Weight: 360 g
- Installation: desktop, wall mount, DIN-rail (with optional kit)
- MTBF: 377,937 hrs
- Certifications: CISPR 32, FCC Part 15B Class A, EN IEC 62368-1, DNV, RoHS, CRoHS, WEEE

FAQs

Q: What serial interfaces does the NPort 5230-T provide?
A: It has two serial ports: one RS-232 port and one RS-422/485 port, both using terminal block connectors.

Q: What is the operating temperature range?
A: The -T model operates from -40 to 75°C, suiting outdoor enclosures and unconditioned industrial cabinets.

Q: What power input does it require?
A: It accepts 12 to 48 VDC through a removable 3-contact terminal block, drawing 325 mA at 12 VDC.

Q: Which operation modes are supported?
A: Real COM, TCP Server, TCP Client, UDP, Pair Connection and Reverse Telnet, as well as Ethernet Modem and Disabled modes.

Q: Can it be mounted on a DIN rail?
A: Yes. It supports desktop and wall mounting, and DIN-rail mounting with the optional DIN-rail kit.

Q: How is the NPort 5230-T configured?
A: Use the Windows utility, serial console, Telnet console or web console (HTTP).

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
