Moxa NM-TX02 | NM Series Network Module, 2x 10/100BaseT(X) RJ45, 0 to 55 °C

Authorised Moxa Partner

SKU:NM-TX02

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa NM-TX02 is a plug-in network expansion module that adds two 10/100BaseT(X) RJ45 Ethernet ports to compatible Moxa NPort 6000 secure terminal servers. This standard-temperature model is rated for 0 to 55 °C operation, making it suited to controlled industrial cabinets and control rooms where the wide-temperature variant is not required.

Built in a metal housing with auto MDI/MDI-X connection and 1.5 kV built-in magnetic isolation protection, the module simplifies cabling and helps protect the host unit. It lets the NPort operate with extra Ethernet ports, for example to support Ethernet redundancy using STP, RSTP or Turbo Ring.

Features

- Adds two 10/100BaseT(X) RJ45 Ethernet ports to supported NPort 6000 terminal servers
- Supports Ethernet redundancy (STP/RSTP/Turbo Ring) with the network module
- Auto MDI/MDI-X for simple cabling
- Built-in 1.5 kV magnetic isolation
- Rugged metal housing
- Standard-temperature model; NM-TX02-T is the wide-temperature variant

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Ethernet ports: 2 x 10/100BaseT(X), RJ45 connector
- Auto MDI/MDI-X connection
- Magnetic isolation protection: 1.5 kV (built-in)
- Housing: Metal
- Operating temperature: 0 to 55 °C (standard temperature model)
- Ambient relative humidity: 5 to 95% (non-condensing)
- EMC: EN 55032/35
- EMI: CISPR 32, FCC Part 15B Class A
- Safety: UL 60950-1
- Traffic control: NEMA TS2
- Vibration: IEC 60068-2-6
- Freefall: IEC 60068-2-34
- Green product: RoHS, CRoHS, WEEE

FAQs

Q: What does the Moxa NM-TX02 do?
A: It is a plug-in expansion module that adds two 10/100BaseT(X) RJ45 Ethernet ports to compatible Moxa NPort 6000 secure terminal servers.

Q: Which devices is the NM-TX02 compatible with?
A: It is part of the NM Series expansion modules used with the Moxa NPort 6400/6600 Series terminal servers. Check the host unit's module support before ordering.

Q: What is the operating temperature range?
A: The NM-TX02 is the standard-temperature model, rated for 0 to 55 °C. The NM-TX02-T is the wide-temperature variant rated for -40 to 75 °C.

Q: Does the module support Ethernet redundancy?
A: Yes, it supports Ethernet redundancy using STP, RSTP or Turbo Ring when installed in a compatible host.

Q: Do I need crossover cables?
A: No. The RJ45 ports support auto MDI/MDI-X, so either straight-through or crossover cables can be used.

Q: What isolation protection does it provide?
A: It includes built-in 1.5 kV magnetic isolation on the Ethernet ports.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
