Moxa NM-FX02-S-SC-T | NM-FX02 2-Port 100BaseFX Fibre Module, SM SC, -40 to 75C

Authorised Moxa Partner

SKU:NM-FX02-S-SC-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa NM-FX02-S-SC-T is a 2-port 100BaseFX single-mode fibre expansion module with SC connectors, designed for NPort 6400 and 6600 series terminal servers. It adds two fibre Ethernet ports for long-distance serial-over-IP links of up to 40 km, and as the -T wide-temperature variant it is rated for -40 to 75C operation in harsh industrial sites.

The metal-housed module extends the optional RJ45 and fibre Ethernet port capacity of compatible NPort 6400 and 6600 units. It uses 1310 nm single-mode optics with a 29 dB link budget, and is RoHS, CRoHS and WEEE compliant.

Features

- Adds two 100BaseFX single-mode fibre ports to NPort 6400/6600 series terminal servers
- SC fibre connectors for standard single-mode cabling
- Up to 40 km typical reach for long-distance links
- Wide-temperature -T variant for harsh industrial environments
- Rugged metal housing
- RoHS, CRoHS and WEEE compliant

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x 100BaseFX ports, single-mode, SC connector
- Typical distance up to 40 km (G.652 single-mode fibre)
- Wavelength typical 1310 nm, TX range 1280 to 1340 nm, RX range 1100 to 1600 nm
- Optical power TX 0 to -5 dBm, RX -3 to -34 dBm
- Link budget 29 dB, dispersion penalty 1 dB
- Operating temperature -40 to 75C (-T wide-temperature model)
- Ambient relative humidity 5 to 95% (non-condensing)
- Metal housing
- Compatible with NPort 6400/6600 series
- EMC: EN 55032/35, CISPR 32, FCC Part 15B Class A
- Safety: UL 60950-1
- Vibration: IEC 60068-2-6, freefall: IEC 60068-2-34
- RoHS, CRoHS, WEEE

FAQs

Q: Which devices is the NM-FX02-S-SC-T compatible with?
A: It is an NM Series expansion module for the Moxa NPort 6400 and 6600 series terminal servers, adding optional fibre Ethernet ports.

Q: What fibre type and connector does it use?
A: It uses single-mode fibre (G.652) with SC connectors on two 100BaseFX ports.

Q: How far can it transmit?
A: The typical single-mode distance is up to 40 km at 1310 nm, with a 29 dB link budget.

Q: What is the operating temperature range?
A: As the -T wide-temperature model, it is rated for -40 to 75C.

Q: Does it support multimode fibre?
A: No. This SKU is the single-mode SC version with 100BaseFX ports.

Q: What environmental compliance does it carry?
A: It is RoHS, CRoHS and WEEE compliant and meets EN 55032/35, CISPR 32 and FCC Part 15B Class A EMC requirements.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
