Moxa NM-FX02-S-SC | NPort NM Fibre Network Module, 2x 100BaseFX SC, 40km

Authorised Moxa Partner

SKU:NM-FX02-S-SC

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa NM-FX02-S-SC is a fibre network expansion module that adds two single-mode 100BaseFX ports with SC connectors to compatible Moxa NPort 6400/6600 terminal servers. Single-mode G.652 fibre supports typical link distances of up to 40 km at a 1310 nm typical wavelength, making it well suited to long-distance serial-to-Ethernet deployments across large sites, campuses and industrial facilities.

The plug-in NM Series design lets you extend an existing NPort 6400/6600 with fibre Ethernet connectivity without replacing the terminal server. A 29 dB link budget and a rugged metal housing support dependable operation in demanding environments.

Features

- Adds dual 100BaseFX fibre ports to compatible NPort 6400/6600 terminal servers
- Single-mode SC fibre supports long-distance links up to 40 km
- Plug-in NM Series expansion module design
- Rugged metal housing
- Use an attenuator with single-mode fibre transceivers to prevent damage from excessive optical power

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Ethernet interface: 2 x 100BaseFX ports
- Fibre type: single-mode, G.652, SC connector
- Typical distance: 40 km
- Typical wavelength: 1310 nm
- TX range: 1280 to 1340 nm
- RX range: 1100 to 1600 nm
- TX optical power: 0 to -5 dBm
- RX optical power: -3 to -34 dBm
- Link budget: 29 dB
- Dispersion penalty: 1 dB
- Housing: metal
- Ambient relative humidity: 5 to 95% (non-condensing)
- EMC: EN 55032/35
- EMI: CISPR 32, FCC Part 15B Class A
- Safety: UL 60950-1
- Vibration: IEC 60068-2-6
- Freefall: IEC 60068-2-34
- Green product: RoHS, CRoHS, WEEE

FAQs

Q: What does the NM-FX02-S-SC connect to?
A: It is an NM Series expansion module for compatible Moxa NPort 6400/6600 terminal servers, adding fibre Ethernet ports to the unit.

Q: What type of fibre does it use?
A: It provides two 100BaseFX ports for single-mode fibre (G.652) with SC connectors.

Q: What is the maximum link distance?
A: The typical distance over single-mode fibre is 40 km, with a 29 dB link budget at a 1310 nm typical wavelength.

Q: Can I use it with multimode fibre?
A: No. This is the single-mode SC version. Use a multimode NM Series module if your cabling is multimode.

Q: Do I need an optical attenuator?
A: Moxa advises using an attenuator with single-mode fibre transceivers to prevent damage from excessive optical power on short runs.

Q: Is this module suitable for extended temperature environments?
A: This SKU is the standard temperature version. Check the NPort 6400/6600 datasheet if your site requires a wider operating range.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
