Moxa NM-FX01-S-SC-T | NM Series 100BaseFX Network Module, Single-Mode SC, Wide Temp

Authorised Moxa Partner

SKU:NM-FX01-S-SC-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa NM-FX01-S-SC-T is an NM Series network expansion module that adds one 100BaseFX single-mode fibre Ethernet port with an SC connector to compatible NPort 6400/6600 Series terminal servers. It suits industrial serial-to-Ethernet deployments that need long-distance fibre uplinks, with a typical single-mode reach of 40 km.

This wide-temperature version is rated for operation from -40 to 75 C, making it well suited to harsh environments such as outdoor cabinets, factory floors and utility installations. Single-mode operation uses a 1310 nm wavelength over G.652 fibre with a 29 dB link budget.

Features

- Adds a 100BaseFX single-mode fibre port to compatible NPort 6000 Series devices
- Wide operating temperature range of -40 to 75 C for harsh environments
- SC fibre connector
- Typical single-mode reach of 40 km
- Moxa recommends an attenuator when connecting single-mode fibre transceivers to prevent damage from excessive optical power

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 1 x 100BaseFX port, single-mode fibre, SC connector
- Operating temperature: -40 to 75 C
- Compatible host: NPort 6400/6600 Series
- Fibre type: G.652 single-mode
- Typical distance: 40 km
- Wavelength (typical): 1310 nm
- TX range: 1280 to 1340 nm
- RX range: 1100 to 1600 nm
- TX optical power: 0 to -5 dBm
- RX optical power: -3 to -34 dBm
- Link budget: 29 dB
- Dispersion penalty: 1 dB

FAQs

Q: Which Moxa devices is the NM-FX01-S-SC-T compatible with?
A: It is an expansion module for the NPort 6400/6600 Series terminal servers, extending their Ethernet port options.

Q: What fibre type and connector does this module use?
A: It provides one 100BaseFX port for G.652 single-mode fibre with an SC connector.

Q: What operating temperature range does it support?
A: This wide-temperature model is rated for -40 to 75 C operation.

Q: How far can it transmit over single-mode fibre?
A: The typical single-mode distance is 40 km at a 1310 nm wavelength, with a 29 dB link budget.

Q: Do I need an attenuator with this module?
A: Moxa recommends using an attenuator when connecting single-mode fibre transceivers to prevent damage from excessive optical power on short links.

Q: Can it be used for multimode fibre links?
A: No. This SKU is the single-mode SC version with one 100BaseFX port, so multimode links need a multimode NM Series module.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
