Moxa NM-FX01-S-SC | NM Series 100BaseFX Fibre Module, Single-Mode, SC, 40km

Authorised Moxa Partner

SKU:NM-FX01-S-SC

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The NM-FX01-S-SC is an NM Series 100BaseFX fibre expansion module that adds one single-mode SC fibre port to compatible Moxa NPort 6450 and 6650 terminal servers. It suits long-distance, EMI-immune fibre uplinks, with a typical reach of up to 40 km on G.652 single-mode fibre at 1310 nm. This is the standard temperature variant.

The module installs in the NM expansion slot of NPort 6000 Series units and complies with IEEE 802.3u 100BaseFX for interoperability with standard fibre Ethernet equipment. It offers a 29 dB link budget and extends the RJ45 and fibre Ethernet options available on compatible NPort units. When connecting a single-mode fibre transceiver, an attenuator is recommended to prevent damage from excessive optical power.

Features

- Adds a single-mode fibre uplink to compatible Moxa NPort platforms
- Long-distance, noise-immune connectivity over SC single-mode fibre
- Standards-compliant 100BaseFX for interoperability
- Simple installation in the NM expansion slot
- Extends RJ45 and fibre Ethernet port options on NPort 6000 units

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Interface: 1 x 100BaseFX single-mode
- Connector: SC
- Fibre cable type: G.652 single-mode
- Typical distance: 40 km
- Wavelength: 1310 nm typical
- TX range: 1280 to 1340 nm
- RX range: 1100 to 1600 nm
- TX optical power: 0 to -5 dBm
- RX optical power: -3 to -34 dBm
- Link budget: 29 dB
- Dispersion penalty: 1 dB
- Standard: IEEE 802.3u 100BaseFX
- Compatible hosts: NPort 6450 and NPort 6650
- Operating temperature: standard temperature

FAQs

Q: Which Moxa devices is the NM-FX01-S-SC compatible with?
A: It is an NM Series plug-in expansion module for the NPort 6450 and NPort 6650 units, installed in the NM expansion slot.

Q: What fibre type and distance does this module support?
A: It supports G.652 single-mode fibre with a typical distance of up to 40 km at a typical wavelength of 1310 nm.

Q: What connector does the module use?
A: It uses one SC connector for its single 100BaseFX port.

Q: Do I need an attenuator?
A: When connecting a single-mode fibre transceiver, an attenuator is recommended to prevent damage from excessive optical power.

Q: Is this the wide temperature version?
A: No. This SKU is the standard temperature variant. The -T variant is the one rated for -40 to 75 C.

Q: What Ethernet standard does it comply with?
A: It complies with IEEE 802.3u 100BaseFX.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
