Moxa NM-FX01-M-SC | NM Series 100BaseFX Fiber Module, Multi-mode, SC

Authorised Moxa Partner

SKU:NM-FX01-M-SC

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The NM-FX01-M-SC is a 1-port 100BaseFX multi-mode fibre Ethernet expansion module with an SC connector, built for standard temperature environments. It adds a fibre Ethernet port to compatible Moxa NPort terminal servers, giving serial-to-Ethernet deployments a fibre uplink for electrically noisy or long-run installations.

The module supports a typical multi-mode link distance of 4 km over OM1 50/125 um fibre and is designed for the NPort 6450, 6610 and 6650. Use it where an optional fibre port is needed alongside the host's standard copper interfaces.

Features

- Expansion module for optional extension of fibre Ethernet ports on NPort 6000 terminal servers
- Multi-mode 100BaseFX fibre link up to 4 km typical
- SC fibre connector
- Compatible with NPort 6450, 6610 and 6650

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Interface: 1 x 100BaseFX
- Fibre mode: Multi-mode
- Connector: SC
- Fibre cable type: OM1 50/125 um
- Typical distance: 4 km
- Typical wavelength: 1300 nm
- TX range: 1260 to 1360 nm
- RX range: 1100 to 1600 nm
- Optical power TX: -10 to -20 dBm
- Optical power RX: -3 to -32 dBm
- Link budget: 12 dB
- Dispersion penalty: 3 dB
- Compatible hosts: NPort 6450, 6610, 6650
- Standard operating temperature

FAQs

Q: Which Moxa devices is the NM-FX01-M-SC compatible with?
A: It is designed as an expansion module for the NPort 6450, NPort 6610 and NPort 6650 terminal servers.

Q: What type of fibre does this module use?
A: It is a multi-mode 100BaseFX module with an SC connector, intended for OM1 50/125 um fibre.

Q: What is the typical link distance?
A: The typical multi-mode distance is 4 km, with a 12 dB link budget.

Q: How many ports does the module add?
A: It adds one 100BaseFX fibre Ethernet port to the host terminal server.

Q: Is this module suitable for extended temperature environments?
A: This SKU is the standard temperature version. Moxa offers a separate -T variant for the extended -40 to 75 C range.

Q: Can I use it with single-mode fibre?
A: No. This model is multi-mode only. A separate single-mode NM Series module is required for single-mode links.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
