Moxa NE-4110S-T | NE-4100 Serial Device Server Module, RS-232, -40 to 75°C

Authorised Moxa Partner

SKU:NE-4110S-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The NE-4110S-T is an embedded NE-4100 serial device server module that connects an RS-232 serial device to a 10/100 Mbps Ethernet network through an RJ45 port. This -T variant is rated for -40 to 75°C wide temperature operation, making it suited to manufacturers integrating network connectivity into industrial equipment deployed in harsh environments.

The ready-to-go pin header module measures 57 x 40 mm and runs from a single 5 VDC input at 1.5 W. It supports Real COM, TCP Server, TCP Client and UDP operation modes, with Windows, Linux, fixed TTY and Android drivers available for host integration.

Features

- Supports baudrates up to 230.4 kbps
- Choice of operation modes: Real COM, TCP Server, TCP Client and UDP
- Supports DHCP, BootP, Static IP and ARP
- SNMP and email alerts for event trapping and notifications
- Low power consumption at 1.5 W with a single 5 V input
- Real COM driver included for backward compatibility
- Windows, Linux, fixed TTY and Android drivers available
- Configurable via web console, Telnet, serial console or Windows utility

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 1 x 10/100BaseT(X) Ethernet port (RJ45, auto MDI/MDI-X)
- 1 x RS-232 serial port plus 1 TTL console port
- Baudrate 110 bps to 230.4 kbps
- Operation modes: Real COM, TCP Server, TCP Client, UDP
- Serial signals (RS-232): TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- Data bits 5, 6, 7, 8; stop bits 1, 1.5, 2
- Built-in 1.5 kV magnetic isolation protection
- Input voltage 5 VDC, 290 mA, 1.5 W power consumption
- Operating temperature -40 to 75°C
- Embedded pin header module, 57 x 40 mm, 40 g
- MTBF 290,276 hrs (Telcordia SR332)

FAQs

Q: What serial interface does the NE-4110S-T support?
A: It provides one RS-232 serial port with TxD, RxD, RTS, CTS, DTR, DSR, DCD and GND signals, plus a TTL console port for configuration.

Q: What is the operating temperature range?
A: This -T variant operates from -40 to 75°C, suiting it to wide temperature industrial applications.

Q: What power supply does it need?
A: It runs from a 5 VDC input and draws 290 mA, which is 1.5 W of power consumption.

Q: Which operation modes are available?
A: Real COM, TCP Server, TCP Client and UDP modes are supported, allowing it to suit both legacy COM-port software and socket-based applications.

Q: Is this a standalone device server?
A: No. It is an embedded pin header module (57 x 40 mm) designed to be integrated into your own equipment, rather than a DIN-rail or desktop unit.

Q: Which operating systems have driver support?
A: Real COM drivers are available for Windows, including Embedded CE and XP Embedded, and Real TTY drivers for Linux. Fixed TTY drivers cover several UNIX variants and Mac OS X, and an Android API is also provided.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
