Moxa CP-118EL-A w/o Cable | CP-118EL 8-Port RS-232/422/485 PCIe Serial Board, w/o Cable

Authorised Moxa Partner

SKU:CP-118EL-A w/o Cable

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The CP-118EL-A w/o Cable is an 8-port RS-232/422/485 low-profile PCI Express x1 serial board for POS, ATM and industrial automation systems. Each port can be set independently to RS-232, RS-422 or RS-485 (2-wire or 4-wire), with baudrates up to 921.6 kbps and a 128-byte FIFO for fast, reliable data transmission. This variant ships without a connector cable, so you can pair it with the cable or connection box that suits your installation.

The low-profile form factor fits small-sized PCs, and the board uses a VHDCI 68 connector with full modem control signals. Up to 8 boards can be installed in one PC, and drivers are provided for Windows, Linux and UNIX, with WEPOS also supported for embedded integration. Built-in LEDs and management software simplify day-to-day maintenance.

Features

- PCI Express 1.0 compliant
- 921.6 kbps maximum baudrate for fast data transmission
- 128-byte FIFO and on-chip hardware and software flow control
- Variety of connection cables and boxes available for RS-232/422/485
- Low-profile form factor fits small-sized PCs
- Drivers provided for Windows, Linux and UNIX, with WEPOS also supported for embedded integration
- Built-in LEDs and management software for easy maintenance

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 8 x serial ports, software-selectable RS-232/422/485 (2-wire and 4-wire)
- Bus: PCI Express 1.0 (x1), low-profile form factor
- Connector: VHDCI 68
- Communication controller: 16C550C compatible
- 128-byte FIFO
- Baudrate: 50 bps to 921.6 kbps (supports non-standard baudrates)
- Data bits: 5, 6, 7, 8; Stop bits: 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow control: None, RTS/CTS, XON/XOFF
- Full modem control signals
- Max. 8 boards per PC
- 3.3 VDC power supply
- Operating temperature: 0 to 55°C (32 to 131°F)
- Certifications: CE, FCC
- Variant: without cable

FAQs

Q: Does the CP-118EL-A w/o Cable include a connector cable?
A: No. This variant ships without a connector cable, so you will need to source a compatible cable or connection box separately for the VHDCI 68 connector.

Q: Which serial interfaces does each port support?
A: Each of the 8 ports is software-selectable between RS-232, RS-422 and RS-485 (2-wire or 4-wire), and the mode can be set independently per port.

Q: What PCI Express slot does this board require?
A: It is a PCI Express 1.0 x1 board in a low-profile form factor, suited to small-sized PCs.

Q: Which operating systems are supported?
A: Drivers are provided for Windows, Linux and UNIX, and WEPOS is also supported for embedded integration.

Q: How many boards can be installed in one PC?
A: Up to 8 boards can be installed in a single PC.

Q: What is the maximum baudrate?
A: The board supports baudrates from 50 bps up to 921.6 kbps, including non-standard baudrates.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
