Moxa CP-104UL-DB9M | CP-104UL/104JU 4-Port RS-232 Low-Profile PCI Serial Board, DB9 Cable

Authorised Moxa Partner

SKU:CP-104UL-DB9M

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa CP-104UL-DB9M is a 4-port RS-232 low-profile Universal PCI serial board for POS, ATM and industrial automation systems. It supports both 3.3 V and 5 V PCI buses, delivers up to 921.6 kbps on each port, and includes a CBL-M44M9x4-50 fan-out cable that breaks the DB44 board connector out to four DB9 male ports. Operating range is 0 to 55°C.

Each port provides full modem control signals, a 128-byte FIFO and on-chip hardware and software flow control, so it connects to a wide range of serial peripherals. Drivers are available for Windows, Linux and UNIX variants, and up to 8 boards can be installed in a single PC.

Features

- Over 800 kbps data throughput
- 921.6 kbps maximum baudrate on each port
- 128-byte FIFO with on-chip hardware and software flow control
- Full modem control signals for compatibility with a wide range of serial peripherals
- Drivers for Windows, Linux and UNIX (QNX 6, SCO OpenServer, UnixWare 7, Solaris 10, FreeBSD)
- Low-profile form factor
- Universal PCI design works with 3.3 V and 5 V PCI slots

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 4 x RS-232 serial ports
- 32-bit Universal PCI bus (3.3/5 V PCI and PCI-X compatible)
- Communication controller: MU860 (16C550C compatible)
- Board connector: DB44 female
- Included cable: CBL-M44M9x4-50 (DB44 to 4 x DB9 male)
- Baudrate: 50 bps to 921.6 kbps
- 128-byte FIFO
- Flow control: None, RTS/CTS, XON/XOFF
- Data bits 5/6/7/8; stop bits 1/1.5/2; parity None/Even/Odd/Space/Mark
- Serial signals: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- Maximum 8 boards per PC
- Input current: 120 mA @ 5 VDC
- Dimensions: 64.4 x 120 mm (2.53 x 4.72 in)
- Operating temperature: 0 to 55°C
- Storage temperature: -40 to 85°C
- Built-in Tx/Rx LEDs for each port

FAQs

Q: What cable is included with the CP-104UL-DB9M?
A: It ships with the CBL-M44M9x4-50 fan-out cable, which converts the DB44 female board connector into four DB9 male RS-232 connectors.

Q: Which PCI slots is this board compatible with?
A: It is a 32-bit Universal PCI board that works with both 3.3 V and 5 V PCI buses and is compatible with PCI-X.

Q: Which operating systems are supported?
A: Drivers are available for Windows, Linux and UNIX variants including QNX 6, SCO OpenServer, UnixWare 7, Solaris 10 and FreeBSD.

Q: How many of these boards can be installed in one PC?
A: Up to 8 boards can be installed in a single PC, which gives a maximum of 32 RS-232 ports.

Q: What is the maximum baudrate per port?
A: Each port supports baudrates from 50 bps to 921.6 kbps.

Q: Does it support low-profile slots?
A: Yes, it is a low-profile board measuring 64.4 x 120 mm, suited to compact industrial PCs, POS terminals and ATMs.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
