Moxa CP-104JU-T | CP-104UL/104JU 4-Port RS-232 Universal PCI Serial Board, RJ45, -40 to 85°C

Authorised Moxa Partner

SKU:CP-104JU-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa CP-104JU-T is a 4-port RS-232 universal PCI serial board with four RJ45 connectors on the board, built for POS and ATM applications. As the -T variant, it supports a wide operating temperature range of -40 to 85°C, making it suited to deployments where standard boards are not rated to operate.

The board uses a 32-bit Universal PCI bus and an MU860 communication controller (16C550C compatible) with a 128-byte FIFO, with baudrates from 50 bps to 921.6 kbps. Up to 8 boards can be installed in a single PC, and driver support spans Windows, Linux and UNIX platforms, including Arm-based systems under Linux kernel 4.x and 5.x.

Features

- Designed for POS and ATM applications
- Wide operating temperature range of -40 to 85°C
- Windows drivers (95/98/ME/NT/2000/XP/Vista/7/8/10/11, Server 2008-2022, Embedded CE 5.0/6.0, XP Embedded)
- Linux drivers (kernel 2.4.x to 5.x)
- UNIX drivers (QNX 6, SCO OpenServer, UnixWare 7, Solaris 10, FreeBSD)
- Arm-based platform support under Linux kernel 4.x/5.x
- Built-in LEDs

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 4 x RS-232 serial ports
- 32-bit Universal PCI bus
- 4 x RJ45 connectors
- MU860 communication controller (16C550C compatible)
- 128-byte FIFO
- Baudrate 50 bps to 921.6 kbps
- Data bits 5, 6, 7, 8
- Stop bits 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow control: None, RTS/CTS, XON/XOFF
- Up to 8 boards per PC
- Operating temperature -40 to 85°C

FAQs

Q: What bus does the Moxa CP-104JU-T use?
A: It uses a 32-bit Universal PCI bus, so it fits both 3.3V and 5V PCI slots.

Q: What serial interface and connectors does it provide?
A: It provides 4 x RS-232 serial ports, each terminated with an RJ45 connector on the board.

Q: What does the -T in CP-104JU-T mean?
A: The -T variant supports an extended operating temperature range of -40 to 85°C.

Q: Which operating systems are supported?
A: Drivers are available for Windows (95 through 11, Server 2008-2022, Embedded CE 5.0/6.0, XP Embedded), Linux (kernel 2.4.x to 5.x), and UNIX systems including QNX 6, SCO OpenServer, UnixWare 7, Solaris 10 and FreeBSD.

Q: How many boards can be installed in one PC?
A: Up to 8 boards can be installed in a single PC.

Q: What serial parameters and speeds are supported?
A: Baudrates range from 50 bps to 921.6 kbps, with 5 to 8 data bits, 1, 1.5 or 2 stop bits, and None, Even, Odd, Space or Mark parity. Flow control options are None, RTS/CTS and XON/XOFF.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
