Moxa CN2650I-16-2AC | CN2600 16-Port RS-232/422/485 Terminal Server, 2kV, Dual AC

Authorised Moxa Partner

SKU:CN2650I-16-2AC

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa CN2650I-16-2AC is a rack-mount terminal server that connects 16 RS-232/422/485 serial devices to an Ethernet network through DB9 male ports. Each serial port carries 2 kV isolation, so a surge on one port does not affect the others, and dual AC power inputs together with dual LAN ports provide power and network redundancy for industrial serial connectivity.

Supporting Real COM, TCP Server, TCP Client, UDP, RFC2217, Terminal, Reverse Telnet and PPP operation modes, it integrates serial equipment into existing industrial networks with Real COM and TTY drivers for Windows, Linux and macOS. Security features include HTTPS, SSHv2, SNMPv3 and AES encryption, making it suited to controlled and critical environments.

Features

- Dual-LAN design with two independent MAC and IP addresses
- Redundant COM function when both LANs are active
- Dual-host redundancy to add a backup PC to the system
- Dual AC power inputs for power redundancy
- Per-port 2 kV isolation protects other ports from surges
- LCD panel for easy IP address configuration
- Real COM and TTY drivers for Windows, Linux and macOS
- Operation modes: Real COM, TCP Server, TCP Client, UDP, RFC2217, Terminal, Reverse Telnet, PPP, DRDAS, Redundant COM
- Security: HTTPS, AES-128/256, HMAC, RSA-1024, SHA-1, SNMPv3, SSHv2
- Built-in watchdog timer for automatic reboot

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 16 x RS-232/422/485 serial ports, DB9 male connectors
- 2 x 10/100BaseT(X) Ethernet ports, RJ45
- 1.5 kV built-in magnetic isolation on Ethernet ports
- 2 kV isolation per serial port
- Baudrate 50 bps to 921.6 kbps
- Data bits 5/6/7/8; stop bits 1/1.5/2; parity None/Even/Odd/Space/Mark
- Flow control: None, RTS/CTS, DTR/DSR, XON/XOFF
- RS-485 automatic data direction control (ADDC)
- RS-485 pull high/low resistor: 1 kilo-ohm or 150 kilo-ohms; 120 ohm terminator
- Console port: RS-232 (TxD, RxD, GND), 8-pin RJ45 (19200, n, 8, 1)
- 2 x AC power inputs, 100 to 240 VAC, 50/60 Hz
- Input current 130 mA @ 110 VAC
- Operating temperature 0 to 55 °C (32 to 131 °F)
- Rack-mount form factor
- Safety approval: UL 62368-1

FAQs

Q: How many serial ports does the Moxa CN2650I-16-2AC provide?
A: It provides 16 serial ports, each configurable as RS-232, RS-422 or RS-485 and terminated with DB9 male connectors.

Q: Does it offer power redundancy?
A: Yes. It has two AC power inputs accepting 100 to 240 VAC at 50/60 Hz, so the unit can run from two independent power feeds.

Q: What isolation does it provide?
A: Each serial port has 2 kV isolation, and the Ethernet ports have 1.5 kV built-in magnetic isolation.

Q: Does it support network redundancy?
A: Yes. The dual-LAN design uses two Ethernet ports with independent MAC and IP addresses, and the Redundant COM function operates when both LANs are active.

Q: Which operating systems are supported by the drivers?
A: Real COM and TTY drivers are available for Windows, Linux and macOS.

Q: What operation modes are available?
A: Real COM, TCP Server, TCP Client, UDP, RFC2217, Terminal, Reverse Telnet, PPP, DRDAS and Redundant COM modes are supported.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
