Moxa CN2610-8 | CN2600 Dual-LAN Terminal Server, 8x RS-232, AC, 0-55°C

Authorised Moxa Partner

SKU:CN2610-8

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa CN2610-8 is a dual-LAN terminal server with 8 RS-232 serial ports on RJ45 connectors, designed to connect industrial serial devices to Ethernet networks. Two independent 10/100 Mbps Ethernet ports support Redundant COM and dual-host redundancy, keeping serial data flowing if a network path or host fails. This model uses a single 100 to 240 VAC power input and operates from 0 to 55°C.

The CN2610-8 supports Real COM, TCP Server, TCP Client, UDP, RFC2217, Terminal, Reverse Telnet, PPP and DRDAS operation modes, with Real COM and TTY drivers for Windows, Linux and macOS. Security features include SNMPv3, SSHv2, HTTPS, RADIUS authentication and AES-128/256 encryption, with a dedicated RS-232 console port for local management.

Features

- LCD panel for easy IP address configuration
- Dual-LAN cards with two independent MAC addresses and IP addresses
- Redundant COM function available when both LANs are active
- Dual-host redundancy to add a backup PC to the system
- Real COM and TTY drivers for Windows, Linux and macOS
- Universal 100 to 240 VAC power input

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x 10/100BaseT(X) Ethernet ports (RJ45), 1.5 kV built-in magnetic isolation
- 8 x RS-232 serial ports, 8-pin RJ45 connector
- Baudrate 50 bps to 921.6 kbps
- Data bits 5, 6, 7, 8; stop bits 1, 1.5, 2; parity None/Even/Odd/Space/Mark
- Flow control: RTS/CTS, DTR/DSR, XON/XOFF
- Dedicated RS-232 console port
- Operation modes: Real COM, TCP Server, TCP Client, UDP, RFC2217, Terminal, Reverse Telnet, PPP, DRDAS, Redundant COM
- Security: SNMPv3, SSHv2, HTTPS, RADIUS authentication, AES-128/256
- Power: 1 input, 100 to 240 VAC (50/60 Hz), 130 mA @ 110 VAC
- Operating temperature 0 to 55°C
- Built-in WDT, buzzer and RTC
- MTBF 831,925 hrs (Telcordia)
- Certifications: CISPR 32, FCC Part 15B Class A, EN 55032/24, UL 60950-1, RoHS, CRoHS, WEEE

FAQs

Q: How many serial ports does the Moxa CN2610-8 have?
A: It has 8 RS-232 serial ports on 8-pin RJ45 connectors, plus a dedicated RS-232 console port.

Q: What does the dual-LAN design provide?
A: Two independent 10/100 Mbps Ethernet ports, each with its own MAC and IP address. This enables the Redundant COM function and dual-host redundancy for resilient serial connectivity.

Q: Which operating systems are supported by the drivers?
A: Real COM and TTY drivers are available for Windows, Linux and macOS.

Q: What operation modes does it support?
A: Real COM, TCP Server, TCP Client, UDP, RFC2217, Terminal, Reverse Telnet, PPP, DRDAS and Redundant COM.

Q: What power input does the CN2610-8 use?
A: A single AC input rated 100 to 240 VAC at 50/60 Hz.

Q: Is the CN2610-8 suitable for wide-temperature environments?
A: This model operates from 0 to 55°C, so it suits standard-temperature installations rather than wide-temperature deployments.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
