Moxa CN2610-8-2AC | CN2600 8-Port RS-232 Terminal Server, Dual LAN, Dual AC

Authorised Moxa Partner

SKU:CN2610-8-2AC

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The CN2610-8-2AC is an 8-port RS-232 rack-mount terminal server with dual 10/100 Ethernet LAN ports and dual AC power inputs. It gives serial consoles and industrial devices reliable network access, with the redundant LAN and power design suited to industrial and data-centre environments where uptime matters.

Eight RJ45 serial ports support baud rates from 50 bps to 921.6 kbps with full RS-232 signalling. Operation modes include Real COM, TCP Server, TCP Client, UDP, RFC2217, Terminal, Reverse Telnet, PPP, DRDAS and Redundant COM, while HTTPS, SSHv2, SNMPv3 and AES encryption protect serial-to-network traffic. The metal housing mounts in a standard 19-inch rack.

Features

- Dual-LAN and dual-AC-power design for redundancy
- Operation modes: Real COM, TCP Server, TCP Client, UDP, RFC2217, Terminal, Reverse Telnet, PPP, DRDAS, Redundant COM
- Security: HTTPS, SSHv2, SNMPv3, AES-128/256 encryption
- Authentication via local database or RADIUS
- Fixed TTY drivers for Linux, SCO UNIX, QNX, Solaris, FreeBSD, AIX, HP-UX, macOS
- Virtual machine support

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 8 x RS-232 serial ports (8-pin RJ45 connector)
- 2 x 10/100BaseT(X) Ethernet ports (RJ45), 1.5 kV built-in magnetic isolation
- Baudrate: 50 bps to 921.6 kbps
- Data bits: 5, 6, 7, 8
- RS-232 signals: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- Dual AC power inputs, 100 to 240 VAC (50/60 Hz), 130 mA @ 110 VAC
- Built-in WDT (watchdog timer), buzzer and RTC
- Metal housing, 19-inch rack mounting
- Dimensions with ears: 480 x 198 x 45.5 mm; without ears: 440 x 198 x 45.5 mm
- Operating temperature: 0 to 55°C
- Storage temperature: 0 to 55°C

FAQs

Q: How many serial ports does the CN2610-8-2AC have and what interface do they use?
A: It has 8 RS-232 serial ports on 8-pin RJ45 connectors, supporting TxD, RxD, RTS, CTS, DTR, DSR, DCD and GND signals.

Q: Does this terminal server support redundant power?
A: Yes. It has dual AC power inputs accepting 100 to 240 VAC at 50/60 Hz, so it keeps running if one power feed fails.

Q: What operation modes are supported?
A: Real COM, TCP Server, TCP Client, UDP, RFC2217, Terminal, Reverse Telnet, PPP, DRDAS and Redundant COM modes are supported.

Q: Which security features are included?
A: It supports HTTPS, SSHv2, SNMPv3 and AES-128/256 encryption, with authentication through a local database or RADIUS.

Q: Can it be mounted in a standard rack?
A: Yes. The metal housing mounts in a 19-inch rack. Dimensions are 480 x 198 x 45.5 mm with mounting ears and 440 x 198 x 45.5 mm without.

Q: Which operating systems have driver support?
A: Fixed TTY drivers are available for Linux, SCO UNIX, QNX, Solaris, FreeBSD, AIX, HP-UX and macOS, and virtual machine environments are supported.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
