Moxa CN2610-16 | Dual-LAN Terminal Server, 16x RS-232, 100-240 VAC

Authorised Moxa Partner

SKU:CN2610-16

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa CN2610-16 is a dual-LAN terminal server with 16 RS-232 serial ports (8-pin RJ45) and a single 100-240 VAC power input. Its two independent 10/100 Ethernet ports, each with its own MAC and IP address, support a Redundant COM mode that keeps serial applications running if one network path fails, making it well suited to rack-based industrial and data centre serial device networking.

The CN2610-16 supports Real COM, TCP Server, TCP Client, UDP, RFC2217, Terminal, Reverse Telnet, PPP, DRDAS and Redundant COM operation modes, with Real COM and TTY drivers for Windows, Linux and macOS. Configuration is available through the LCD panel, serial or Telnet console, Windows utility or the Device Search Utility, and a rack-mounting kit and RJ45-to-DB9 console cable are included.

Features

- LCD panel for easy IP address configuration
- Dual-LAN cards with two independent MAC and IP addresses
- Redundant COM function available when both LANs are active
- Dual-host redundancy to add a backup PC
- Real COM and TTY drivers for Windows, Linux and macOS
- Universal high-voltage range power input, 100 to 240 VAC

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 16 x RS-232 serial ports (8-pin RJ45)
- 2 x 10/100BaseT(X) Ethernet ports (RJ45), 1.5 kV built-in magnetic isolation
- Baudrate 50 bps to 921.6 kbps
- Data bits 5, 6, 7, 8; stop bits 1, 1.5, 2; parity None/Even/Odd/Space/Mark
- Flow control: None, RTS/CTS, DTR/DSR, XON/XOFF
- RS-232 signals: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
- Console port: RS-232, 8-pin RJ45 (19200, n, 8, 1)
- 1 x power input, 100 to 240 VAC (50/60 Hz), 130 mA @ 110 VAC
- Operation modes: Real COM, TCP Server, TCP Client, UDP, RFC2217, Terminal, Reverse Telnet, PPP, DRDAS, Redundant COM
- Configuration: Serial Console, Telnet Console, Windows Utility, Device Search Utility (DSU)
- Package includes 1 x rack-mounting kit and 1 x RJ45-to-DB9 console cable

FAQs

Q: How many serial ports does the Moxa CN2610-16 have and what type are they?
A: The CN2610-16 provides 16 RS-232 serial ports using 8-pin RJ45 connectors.

Q: What is Redundant COM mode?
A: Redundant COM uses the two independent Ethernet ports so that serial applications keep running if one network path fails. It is available when both LANs are active.

Q: Which operating systems are supported by the Real COM drivers?
A: Real COM and TTY drivers are available for Windows, Linux and macOS.

Q: What power input does the CN2610-16 use?
A: It has a single power input rated 100 to 240 VAC (50/60 Hz).

Q: What is included in the box?
A: The package includes a rack-mounting kit and an RJ45-to-DB9 console cable.

Q: How is the CN2610-16 configured?
A: Configuration is available via the LCD panel, serial console, Telnet console, Windows utility or the Device Search Utility (DSU).

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
