Moxa CN2610-16-2AC | CN2600 16-Port RS-232 Terminal Server, Dual-LAN, Dual AC

Authorised Moxa Partner

SKU:CN2610-16-2AC

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa CN2610-16-2AC is a rackmount terminal server with 16 RS-232 serial ports, dual 10/100 Ethernet LAN connections and dual AC power inputs. It connects serial devices to IP networks and suits industrial and data centre environments where console and device access must stay available.

Two independent LAN ports with separate MAC and IP addresses support LAN redundancy and a redundant COM function, while dual-host redundancy allows a backup PC to be added to the system. Real COM/TTY drivers for Windows and Linux, plus HTTPS, SSHv2, SNMPv3 and RADIUS support, make integration and secure management straightforward.

Features

- LCD panel for easy IP address configuration
- Dual-LAN cards with two independent MAC addresses and IP addresses
- Redundant COM function available when both LANs are active
- Dual-host redundancy to add a backup PC to the system
- Dual AC power inputs with redundant internal power supplies
- Real COM/TTY drivers for Windows and Linux

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 2 x 10/100BaseT(X) Ethernet ports (RJ45), 1.5 kV magnetic isolation
- 16 x RS-232 serial ports (8-pin RJ45)
- Baudrate 50 bps to 921.6 kbps
- Data bits 5, 6, 7, 8; stop bits 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow control: None, RTS/CTS, DTR/DSR, XON/XOFF
- Dual AC power inputs, 100-240 VAC
- Operating temperature 0 to 55°C
- 19-inch rackmount
- Security: HTTPS, SSHv2, SNMPv3, RADIUS, AES-128/256
- Real COM/TTY drivers for Windows and Linux

FAQs

Q: How many serial ports does the CN2610-16-2AC have?
A: It has 16 RS-232 serial ports on 8-pin RJ45 connectors, supporting baudrates from 50 bps to 921.6 kbps.

Q: Does it support network redundancy?
A: Yes. It has two independent 10/100 Ethernet LAN ports, each with its own MAC and IP address. The redundant COM function is available when both LANs are active, and dual-host redundancy lets you add a backup PC.

Q: What power inputs does it use?
A: It has dual AC power inputs rated 100-240 VAC with redundant internal power supplies, so it keeps running if one supply or feed fails.

Q: Which operating systems are supported for COM port mapping?
A: Real COM/TTY drivers are available for Windows and Linux, so existing serial applications can access the connected devices over the network.

Q: What security protocols are supported?
A: It supports HTTPS, SSHv2, SNMPv3 and RADIUS, along with AES-128/256 encryption.

Q: How is the IP address configured?
A: The built-in LCD panel allows the IP address to be set directly on the unit without needing a separate console connection.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
