Moxa CN2510-8 | CN2510 8-Port RS-232 Terminal Server, 100-240 VAC, 1U

Authorised Moxa Partner

SKU:CN2510-8

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The Moxa CN2510-8 is a 1U rackmount 8-port RS-232 terminal server designed for remote console management of network equipment such as servers and routers over Telnet. This model provides eight RS-232 serial ports on RJ45 connectors, a 10/100M Ethernet port and a 100-240 VAC power input, with an LCD control panel for convenient on-site configuration.

The CN2510 series supports up to 16 dial-in users when operating as a standalone remote access server, with PPP/SLIP, RADIUS authentication and RIP I/II routing. Real COM and TTY drivers for Windows, Linux and macOS let administrators integrate legacy serial devices into IP-based management workflows, and full modem control signals are supported.

Features

- LCD control panel for easy on-site management
- Supports up to 16 dial-in users when operating as a standalone remote access server
- Supports PPP/SLIP with RADIUS authentication and RIP I/II routing protocols
- Real COM and TTY drivers for Windows, Linux and macOS
- Device Search Utility (DSU), DHCP client, MIB-II

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 8 x RS-232 serial ports, 8-pin RJ45 connector
- 1 x 10/100BaseT(X) Ethernet port (RJ45)
- Operation mode: Terminal mode
- Baudrate: 50 bps to 921.6 kbps
- Data bits: 5, 6, 7, 8; stop bits: 1, 1.5, 2
- Power input: 100-240 VAC
- Operating temperature: 0 to 55 °C
- 1U rackmount form factor
- Full modem control signals supported

FAQs

Q: What is the Moxa CN2510-8 used for?
A: It is a 1U rackmount terminal server for remote console management of network equipment such as servers and routers over Telnet, using its eight RS-232 serial ports.

Q: How many serial ports does the CN2510-8 have and what connector type is used?
A: It has 8 RS-232 serial ports using 8-pin RJ45 connectors, with full modem control signals supported.

Q: What power input does the CN2510-8 require?
A: It operates from a 100-240 VAC power input.

Q: Which operating systems are supported by the Real COM and TTY drivers?
A: Real COM and TTY drivers are available for Windows, Linux and macOS.

Q: What network interface does the CN2510-8 provide?
A: It has one 10/100BaseT(X) Ethernet port with an RJ45 connector.

Q: Can the CN2510-8 act as a remote access server?
A: Yes. As a standalone remote access server it supports up to 16 dial-in users with PPP/SLIP, RADIUS authentication and RIP I/II routing.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
