• Moxa CN2510-8-48V 8-port terminal server with Black Noka switch display and Ethernet ports
1 1

Moxa

Moxa CN2510-8-48V | CN2510 8-Port RS-232 Terminal Server, 48 VDC, Rack

Moxa CN2510-8-48V | CN2510 8-Port RS-232 Terminal Server, 48 VDC, Rack

Authorised Moxa Partner

CN2510-8-48V

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Moxa CN2510-8-48V is an 8-port RS-232 terminal server for rack-mounted serial device connectivity, powered from a +/-48 VDC telecom-style input. It connects eight serial devices to an Ethernet network through eight RJ45 serial ports and a single 10/100BaseT(X) LAN port, making it well suited to telecom rooms and DC-powered equipment racks.

The CN2510 series supports terminal mode operation and can also act as a standalone remote access server with PPP/SLIP, RADIUS authentication and RIP routing. Real COM/TTY drivers for Windows and Linux, an LCD control panel and a 19-inch metal housing make installation and ongoing management straightforward.

Features

- LCD control panel for easy on-site management
- Supports up to 16 dial-in users when operating as a standalone remote access server
- Supports PPP/SLIP with RADIUS authentication and RIP I/II routing protocols
- Real COM/TTY drivers for Windows and Linux
- 48 VDC power input for telecom applications
- 19-inch rack-mount metal housing

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- 8 x RS-232 serial ports, 8-pin RJ45 connectors
- 1 x 10/100BaseT(X) Ethernet port (RJ45) with 1.5 kV magnetic isolation
- Operation mode: Terminal mode
- Baudrate: 50 bps to 921.6 kbps
- Data bits 5, 6, 7, 8; stop bits 1, 1.5, 2
- Parity: None, Even, Odd, Space, Mark
- Flow control: None, RTS/CTS, XON/XOFF
- Power input: +/-48 VDC (38 to 72 VDC, -38 to -72 VDC)
- Input current: 180 mA @ 48 VDC
- Metal housing, 19-inch rack mounting
- Dimensions: 440 x 198 x 45 mm (17.3 x 7.8 x 1.77 in)
- Weight: 2,420 g (5.34 lb)
- Operating temperature: 0 to 55°C (32 to 131°F)
- Storage temperature: -20 to 70°C (-4 to 158°F)
- Ambient relative humidity: 5 to 95% (non-condensing)
- MTBF: 850,673 hrs (Telcordia/Bellcore)
- Security: RADIUS; routing: RIP v1/v2 and static route
- Management: Device Search Utility (DSU), DHCP client, TCP/IP, UDP, MIB-II

FAQs

Q: What power input does the CN2510-8-48V use?
A: It runs from a +/-48 VDC input, with an accepted range of 38 to 72 VDC or -38 to -72 VDC, and draws 180 mA at 48 VDC. It is the DC-powered model of the 8-port CN2510 range.

Q: What serial interface and connectors does it provide?
A: It provides 8 RS-232 serial ports on 8-pin RJ45 connectors, supporting baud rates from 50 bps to 921.6 kbps with None, RTS/CTS and XON/XOFF flow control.

Q: Can it be used as a remote access server?
A: Yes. Besides terminal mode, it can operate as a standalone remote access server supporting up to 16 dial-in users, using PPP/SLIP with RADIUS authentication and RIP I/II routing.

Q: Does it support Windows and Linux?
A: Yes. Real COM/TTY drivers are available for Windows and Linux, so serial applications can access the connected devices as if they were local COM or TTY ports.

Q: How is the CN2510-8-48V mounted?
A: It is built in a 19-inch rack-mount metal housing measuring 440 x 198 x 45 mm, so it fits standard racks.

Q: What network connection does it have?
A: It has a single 10/100BaseT(X) Ethernet RJ45 port with 1.5 kV magnetic isolation for the LAN connection.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
