Arista DCS-7508E-FM | 7500E Fabric-E Module, 5.12 Tbps, Integrated Fan, 7508E
Arista DCS-7508E-FM | 7500E Fabric-E Module, 5.12 Tbps, Integrated Fan, 7508E
Authorised Arista Partner
SKU:DCS-7508E-FM
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The 7500E Series Fabric-E module with integrated fan is the fabric interconnect for the Arista 7508E 8-slot chassis. It delivers 5.12 Tbps of fabric capacity per module and provides non-blocking, active-active connectivity between every line card. This variant is for fabric slots 1-6 in the 7508E chassis, and a fully populated chassis uses six modules in a 5+1 redundant design.
Each module includes an integrated fan assembly for flexible, redundant cooling in the front-to-rear airflow chassis, and the modules are hot-swappable with zero performance degradation. The fabric uses Virtual Output Queueing, a self-healing fabric and a distributed scheduler, spreading packets across all fabric links to avoid drops. Six modules provide 30 Tbps of total system fabric capacity in the 7508.
Features
Features
- Non-blocking architecture interconnecting all line cards
- Always active-active fabric with N+1 redundancy
- Hot-swappable with zero performance degradation
- Integrated fan assembly for flexible and redundant cooling
- Virtual Output Queueing, self-healing fabric and distributed scheduler
- Packets spread across all fabric links for efficient connectivity with no drops
- Designed for the front-to-rear airflow chassis
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Fabric module: DCS-7508E-FM (Fabric-E with integrated fan)
- Chassis support: DCS-7508
- Fabric slots: 1-6
- Fabric capacity per module: 5.12 Tbps
- Total system fabric capacity (7508): 30 Tbps
- Redundancy: 5+1 (N+1)
- Integrated fan module: Yes
- Typical power: 155 W (maximum 195 W)
- Dimensions (HxWxD): 2.5 x 14 x 10.25 in (6.4 x 35.6 x 26 cm)
- Weight: 10 lbs (4.5 kg)
FAQs
Q: Which chassis does the DCS-7508E-FM fit?
A: It is a Fabric-E module with integrated fan for the Arista DCS-7508 (7508E) 8-slot chassis, required for fabric slots 1-6.
Q: How many fabric modules does a 7508E chassis need?
A: The chassis has six fabric module slots, and a fully populated system uses six modules, giving 5+1 redundancy and 30 Tbps of total fabric capacity.
Q: How much fabric capacity does each module provide?
A: Each fabric module provides 5.12 Tbps of fabric capacity.
Q: Can the module be replaced while the chassis is running?
A: Yes. The fabric modules are hot-swappable with zero performance degradation, because the fabric is always active-active with N+1 redundancy.
Q: Does the module include its own cooling?
A: Yes. It has an integrated fan assembly, which supports flexible and redundant cooling in the front-to-rear airflow chassis.
Q: What are the power requirements?
A: Typical power draw is 155 W, with a maximum of 195 W per module. Typical power is measured at 25C ambient with 50% load on all ports.
