• Teltonika TSW210 silver aluminum gigabit switch with 5 Ethernet ports
1 1

Teltonika

Teltonika TSW210 | 8-Port Gigabit Industrial Switch, 2x SFP, DIN Rail

Teltonika TSW210 | 8-Port Gigabit Industrial Switch, 2x SFP, DIN Rail

TSW210

In stock:2

$201.14 Save 26%
$148.67 inc. GST
$135.15 ex. GST
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Teltonika TSW210 is an unmanaged industrial Gigabit Ethernet switch delivering 8 x RJ45 Gigabit ports and 2 x SFP fibre-optic ports in a rugged full-aluminium enclosure. Designed for demanding industrial environments, it supports a wide DC input range of 7–57 VDC, an operating temperature range of -40 °C to 75 °C, and IP30 ingress protection — making it well suited for energy and utilities, industrial automation, and manufacturing deployments. Plug-and-play operation means zero configuration is required, and DIN rail or surface mounting options provide flexible installation in control cabinets or on-site enclosures.

With a non-blocking switching capacity of 20 Gbps, jumbo frame support up to 9216 bytes, and compliance with IEEE 802.3az Energy Efficient Ethernet, the TSW210 combines performance with low power consumption — as little as 1.03 W at idle. Certified to CE, FCC, RoHS, REACH, and UKCA standards, it is ready for global industrial deployments.

Features

- Plug-and-play unmanaged operation — no configuration required
- 8 x Gigabit Ethernet ports (10/100/1000 Mbps) for high-speed wired connectivity
- 2 x SFP ports for long-range single-mode or multimode fibre-optic uplinks
- Rugged full-aluminium housing built for harsh industrial environments
- DIN rail and surface mounting for flexible cabinet or panel installation
- Wide operating temperature range (-40 °C to 75 °C) for demanding deployments
- Wide DC input voltage range (7–57 VDC) via industrial 2-pin power connector
- Energy Efficient Ethernet (IEEE 802.3az) with as low as 1.03 W idle power
- Non-blocking 20 Gbps switching capacity with jumbo frame support (9216 bytes)
- Certified CE, FCC, RoHS, REACH, UKCA — ready for global industrial deployments

Warranty

Teltonika networking products come with a 24-month warranty from the date of purchase. Batteries are covered under a separate 6-month warranty.
https://teltonika-networks.com/support/warranty-repair

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 8 x RJ45 Gigabit Ethernet Ports (10/100/1000 Mbps)
- 2 x SFP Ports for long-range fibre-optic communication
- Non-blocking Switching Capacity: 20 Gbps
- MAC Address Table: 2048 entries
- Jumbo Frame Support: up to 9216 bytes
- IEEE Standards: 802.3i, 802.3u, 802.3ab, 802.3x, 802.3az
- Auto MDI/MDIX crossover
- Input Voltage: 7–57 VDC (2-pin industrial DC power socket)
- Power Consumption: 1.03 W idle / 3.71 W maximum
- Operating Temperature: -40 °C to 75 °C
- Operating Humidity: 10%–90% non-condensing
- Ingress Protection: IP30
- Housing: Full aluminium
- Dimensions: 132 x 44.2 x 95.1 mm
- Weight: 500 g
- Mounting: DIN rail or surface mount
- Certifications: CE, FCC, REACH, RoHS, WEEE, UKCA
- Safety Standard: EN IEC 62368-1:2020+A11:2020

FAQs

Q: Does the TSW210 require any configuration to operate?
A: No. The TSW210 is an unmanaged switch with plug-and-play operation. Simply connect power and devices — no configuration software or management interface is needed.

Q: What fibre-optic connectivity does the TSW210 support?
A: The TSW210 includes 2 x SFP ports that accept standard SFP modules for long-range single-mode or short-range multimode fibre-optic communication, enabling flexible network extension beyond copper cabling distances.

Q: Is the TSW210 suitable for outdoor or harsh industrial environments?
A: Yes. The TSW210 is housed in a full-aluminium enclosure rated IP30, operates across -40 °C to 75 °C, and accepts a wide DC input of 7–57 VDC. It is designed for use in industrial automation, energy and utilities, and manufacturing environments where ruggedisation is required.

Q: What mounting options are available for the TSW210?
A: The TSW210 supports both DIN rail mounting and surface mounting, giving flexibility for installation inside control panels, distribution boards, or equipment enclosures.

Q: What certifications does the TSW210 hold?
A: The TSW210 is certified to CE, FCC, REACH, RoHS, WEEE, and UKCA standards, and meets the EN IEC 62368-1:2020+A11:2020 safety standard, making it suitable for deployment across Australia, the UK, EU, and US markets.
