Arista DCS-7508R3-FM | 7500R3 Series Fabric Module for 7508N Chassis, Slots 1-6
Arista DCS-7508R3-FM | 7500R3 Series Fabric Module for 7508N Chassis, Slots 1-6
Authorised Arista Partner
SKU:DCS-7508R3-FM
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista DCS-7508R3-FM is a 7500R3 Series fabric module for the 7508N 8-slot modular data centre switch chassis. It installs in fabric slots 1-6 and has an integrated fan, providing the switching fabric that interconnects every line card in a non-blocking, any-port-to-any-port architecture.
Fabric modules operate active-active across the chassis, so traffic is spread over all installed modules and redundancy is built in. The modules are hot-swappable with no performance degradation, supporting the 7500R3 platform's 230 Tbps system fabric capacity and up to 48 Bpps forwarding.
Features
Features
- Always active-active fabric modules that provide built-in redundancy
- Hot-swappable with no performance degradation
- Non-blocking any-port-to-any-port connectivity across all line cards
- Line card links spread across the fabric for even traffic distribution
- Integrated fan
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Module type: Fabric module with integrated fan
- Compatible chassis: Arista 7508N (7500R3 Series, 8-slot)
- Installs in fabric slots 1-6
- Six fabric modules operate active-active per chassis
- 7500R3 platform: 230 Tbps system fabric capacity, up to 48 Bpps
FAQs
Q: Which chassis is the DCS-7508R3-FM compatible with?
A: It is designed for the Arista 7508N chassis in the 7500R3 Series, the 8-slot modular data centre switch.
Q: Which slots does this fabric module go in?
A: It is required in fabric slots 1-6 of the 7508N chassis.
Q: Are the fabric modules hot-swappable?
A: Yes, fabric modules are hot-swappable with no performance degradation.
Q: Does the fabric module include a fan?
A: Yes, it has an integrated fan.
Q: How does it provide redundancy?
A: Fabric modules operate active-active, with line card links spread across all installed modules, so redundancy is built into the fabric design.
Q: What fabric capacity does the 7500R3 platform offer?
A: The 7500R3 platform delivers 230 Tbps of system fabric capacity and up to 48 Bpps.
