Arista DCS-7504R3-FM | 7500R3 Series Fabric Module for 7504N Chassis, Slots 1-6
Arista DCS-7504R3-FM | 7500R3 Series Fabric Module for 7504N Chassis, Slots 1-6
Authorised Arista Partner
SKU:DCS-7504R3-FM
Stock Status: Enquire
Couldn't load pickup availability
Description
Description
The Arista DCS-7504R3-FM is a 7500R3 Series fabric module for the Arista 7504N 4-slot, 7 RU modular chassis. It is required in fabric slots 1-6, with six modules fitted per chassis, and interconnects all line cards in a non-blocking active-active fabric. The integrated fan module provides flexible and redundant cooling, so no separate fan tray is needed for this module.
Packets are spread across the fabric links for any-port-to-any-port connectivity, and the chassis supports system throughput of 76.8 Tbps and 16 Bpps. The module is hot-swappable, and the fabric degrades gracefully if a module fails, giving deterministic behaviour. It supports the full range of 7500R3 and 7500R3K line cards.
Features
Features
- Interconnects all line cards in a non-blocking architecture irrespective of traffic
- Packets are spread across fabric links for 100% efficient any-port-to-any-port connectivity with no drops
- Active-active fabric modules provide redundancy
- Hot-swappable with zero performance degradation
- Integrated fan assembly provides flexible and redundant cooling
- Graceful degradation on module failure for deterministic behaviour
- Supports the full range of 7500R3 and 7500R3K line cards
Warranty
Warranty
Arista hardware products come with a 1-year limited hardware warranty, covering defects in materials and workmanship under normal use.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Arista products. Contact our team to explore options that align with your organisation's needs.
https://www.arista.com/assets/data/pdf/Warranty.pdf
All technical data should be verified on the manufacturer data sheets.
View full details
What's the difference between add to cart, backorder & request a quote?
Add to Cart lets you purchase in-stock products immediately.
Backorder is available for items that are out of stock. Placing a backorder secures your order; contact us to confirm ETA before ordering if you need it urgently.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Compatible chassis: DCS-7504N (4-slot, 7 RU)
- Required in fabric slots 1-6 (six modules per chassis)
- Redundancy: graceful degradation
- Integrated fan module: Yes
- Typical power: 130 W (max 230 W)
- Dimensions (H x W x D): 2.5 x 8.5 x 10.25 in (6.4 x 21.6 x 26 cm)
- Weight: 7.5 lbs (3.4 kg)
- 7504N chassis system throughput: 76.8 Tbps / 16 Bpps
- Typical power measured at 25C ambient, 50% load on all ports, excluding optics
FAQs
Q: Which chassis is the DCS-7504R3-FM compatible with?
A: It is designed for the Arista DCS-7504N 4-slot, 7 RU modular chassis and is installed in fabric slots 1-6.
Q: How many fabric modules does a 7504N chassis need?
A: The 7504N has six fabric module slots, and this module is required in fabric slots 1-6.
Q: Does the module include its own cooling?
A: Yes. It has an integrated fan module that provides flexible and redundant cooling.
Q: Is the fabric module hot-swappable?
A: Yes. It is hot-swappable with zero performance degradation, and the fabric degrades gracefully if a module fails.
Q: Which line cards work with this fabric module?
A: It supports the full range of 7500R3 and 7500R3K line cards.
Q: What are the power requirements of the module?
A: Typical power draw is 130 W, with a maximum of 230 W. Typical power is measured at 25C ambient with 50% load on all ports, excluding optics.
