Moxa PWR-2190-DC-48V | TRC-2190 48 VDC Redundant Power Supply Module

Moxa PWR-2190-DC-48V | TRC-2190 48 VDC Redundant Power Supply Module

Authorised Moxa Partner

SKU:PWR-2190-DC-48V

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Moxa PWR-2190-DC-48V is a redundant power supply module for the TRC-2190 18-slot rackmount managed media converter chassis. It accepts a 48 VDC input (36 to 53 VDC range) and adds a second power input to the chassis, improving uptime in industrial networking and telecom-style deployments.

The TRC-2190 platform uses a fanless design, which reduces servicing costs, and is rated for operation from -20 to 55°C with IP30 protection. Fitting this module gives the 19-inch rackmount chassis dual power inputs with redundancy, so a single feed failure does not take down your media converter cards.

Features

- Optional redundant power expansion module for the TRC-2190 chassis
- Supports dual power inputs with redundancy
- 48 VDC input with a wide 36 to 53 VDC range
- Fanless chassis design reduces servicing costs
- Operates across -20 to 55°C
- 19-inch rackmount chassis compatibility

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Input voltage: 36 to 53 VDC (48 VDC nominal)
- Type: redundant power supply module for the TRC-2190 chassis
- Number of power inputs on chassis: 2
- Overload current protection supported
- Chassis power consumption (TRC-2190-DC-48V): 3.2 A at 48 VDC
- Fanless chassis design
- Operating temperature: -20 to 55°C (-4 to 131°F)
- IP rating: IP30
- Chassis dimensions: 440 x 260 x 77 mm (18.6 x 11 x 3.3 in)
- Installation: 19-inch rack mounting
- MTBF: 1,055,112 hrs

FAQs

Q: Which chassis is the PWR-2190-DC-48V designed for?
A: It is an optional redundant power supply module for the Moxa TRC-2190 18-slot rackmount managed media converter chassis.

Q: What input voltage does this module accept?
A: It accepts a 48 VDC nominal input, with an input range of 36 to 53 VDC.

Q: What does this module add to the TRC-2190 chassis?
A: It provides a second power input, giving the chassis redundant dual power inputs for greater reliability.

Q: Can I use it with an AC-powered setup?
A: This is the 48 VDC variant, so it is intended for DC power feeds in the 36 to 53 VDC range. Choose an AC-input module if your site is AC powered.

Q: What operating temperature does the TRC-2190 platform support?
A: The TRC-2190 chassis is rated for -20 to 55°C (-4 to 131°F) and is fanless with IP30 protection.

Q: How is the chassis mounted?
A: The TRC-2190 is a 19-inch chassis designed for rack mounting.
