Moxa

Moxa PWR-12150-AU-S2 | PWR Series 12 VDC 1.5 A AU Power Adapter, Barrel Plug

Moxa PWR-12150-AU-S2 | PWR Series 12 VDC 1.5 A AU Power Adapter, Barrel Plug

Authorised Moxa Partner

SKU:PWR-12150-AU-S2

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The PWR-12150-AU-S2 is a 12 VDC, 1.5 A AC-DC power adapter with an Australian plug, designed to power Moxa industrial networking products. It accepts a wide 100 to 240 VAC input and delivers regulated 12 VDC through a non-locking S-type barrel connector (5.5/2.1/9.5 mm), making it a simple replacement or spare supply for compatible Moxa devices.

This AU plug, non-locking barrel plug (S2) variant is rated for operation from 0 to 40°C and carries RCM certification for Australian use. The 1.5 metre cord, compact housing and light 115 g weight suit desktop, cabinet and light-duty installations where a standard mains outlet is available.

Features

- 100 to 240 VAC wide-range power input
- Reliable power source for many Moxa products
- Non-locking (S2) barrel plug for simple connection
- Australian plug type with RCM certification

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Input: 100 to 240 VAC, 50 to 60 Hz
- Output: 12 VDC, 1.5 A
- Input plug type: Australia (AU)
- Output plug: S-Type barrel 5.5/2.1/9.5 mm (non-locking)
- Barrel plug outer diameter: 5.5 ± 0.1 mm
- Barrel plug inner diameter: 2.1 ± 0.1 mm
- Operating temperature: 0 to 40°C
- Storage temperature: -20 to 70°C
- Dimensions: 70 x 55 x 56 mm
- Weight: 115 g
- Cord length: 1500 ± 100 mm
- Safety certification: RCM

FAQs

Q: What output does the PWR-12150-AU-S2 provide?
A: It delivers 12 VDC at up to 1.5 A through a 5.5/2.1/9.5 mm S-type barrel connector.

Q: What input voltage does this adapter accept?
A: It accepts 100 to 240 VAC at 50 to 60 Hz, and is fitted with an Australian plug.

Q: Does the barrel plug lock in place?
A: No. The S2 variant uses a non-locking barrel plug, so it plugs in and pulls out without a locking collar.

Q: What is the operating temperature range?
A: This standard model operates from 0 to 40°C and can be stored from -20 to 70°C.

Q: Is it certified for use in Australia?
A: Yes. The AU model carries RCM safety certification and uses an Australian mains plug.

Q: Can it power any 12 V device?
A: It is intended for Moxa products that use a 12 VDC supply with a 5.5/2.1 mm barrel input. Check your device's rated input voltage, current and connector type before ordering.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
