• Moxa PWR-12050-AU-S2 black plastic AC adapter with coiled cord and DC plug
1 1

Moxa

Moxa PWR-12050-AU-S2 | 12V DC 0.5A Power Adapter, AU Plug, S-Type Barrel

Moxa PWR-12050-AU-S2 | 12V DC 0.5A Power Adapter, AU Plug, S-Type Barrel

Authorised Moxa Partner

PWR-12050-AU-S2

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Moxa PWR-12050-AU-S2 is a 12 VDC, 0.5 A AC-to-DC power adapter with an Australian input plug, designed to power Moxa industrial networking and serial devices from a standard wall outlet. It accepts a wide 100 to 240 VAC input and delivers regulated 12 VDC through an unlocking (non-locking) S-Type 5.5/2.1/9.5 barrel plug for quick, tool-free connection.

With an operating temperature range of 0 to 40°C and a 1.5 m output cord, this plug-in adapter suits cabinet, desk and light industrial deployments. It is RCM-certified for use in Australia and serves as a reliable power source for many Moxa products.

Features

- 100 to 240 VAC wide-range power input
- Reliable power source for many Moxa products
- Unlocking (non-locking) S2 barrel plug for easy connection
- RCM-certified for Australia
- Australian input plug for direct use with local wall outlets

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Input: 100 to 240 VAC, 50 to 60 Hz
- Output: 0.5 A @ 12 VDC
- Input plug type: AU (Australia)
- Output connector: S-Type 5.5/2.1/9.5 barrel plug (unlocking / non-locking)
- Operating temperature: 0 to 40°C (32 to 104°F)
- Storage temperature: -20 to 70°C (-4 to 158°F)
- Weight: 81 g (0.18 lb)
- Cord length: 1500±100 mm (59.06±3.94 in)
- Safety approval: RCM

FAQs

Q: What output does the Moxa PWR-12050-AU-S2 provide?
A: It delivers 0.5 A at 12 VDC through an S-Type 5.5/2.1/9.5 barrel plug.

Q: What input voltage does it accept?
A: It accepts 100 to 240 VAC at 50 to 60 Hz, so it works across a wide range of mains supplies.

Q: Does this adapter have a locking barrel plug?
A: No. The S2 barrel plug is an unlocking (non-locking) type, which makes it quick to connect and disconnect.

Q: Is the PWR-12050-AU-S2 suitable for use in Australia?
A: Yes. It has an Australian (AU) input plug and carries RCM safety approval.

Q: What is the operating temperature range?
A: The adapter operates from 0 to 40°C (32 to 104°F) and can be stored from -20 to 70°C.

Q: How long is the output cord?
A: The output cord is approximately 1500 mm (about 59 inches).

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
