Moxa ioPAC 8600-PW10-30W-T | ioPAC 8600 Power Supply Module, 24-110 VDC, 30W, Dual Input, -40 to 75°C

Authorised Moxa Partner

SKU:ioPAC 8600-PW10-30W-T

Stock Status: Enquire

Request Quote

Sale Stock Status: Enquire

Shipping calculated at checkout.

Description

The ioPAC 8600-PW10-30W-T is a power supply module for the ioPAC 8600 series of rugged modular programmable controllers. It accepts a wide 24 to 110 VDC input across two power inputs for redundancy and delivers 30 W, with an extended -40 to 75°C operating range suited to harsh industrial and railway environments.

Built with a metal housing, spring-type Euroblock terminals and 3 kV VDC galvanic isolation, the module meets EN 50155 and EN 50121-4 railway standards and carries UL 508 safety approval. It is designed to power ioPAC 8600 controller and I/O configurations in transportation, energy and factory automation deployments.

Features

- Power module for ioPAC 8600 series modular controllers
- Dual power inputs for redundancy
- Wide 24 to 110 VDC input range
- Extended -40 to 75°C operating temperature for harsh environments
- Railway standards compliance (EN 50155, EN 50121-4)
- 3 kV VDC galvanic isolation
- Rugged metal housing
- Spring-type Euroblock terminal for secure wiring

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Input voltage: 24 to 110 VDC
- Number of power inputs: 2 (dual redundant)
- Power output: 30 W
- Power connector: Spring-type Euroblock terminal
- Galvanic isolation: 3 kV VDC
- Wiring: 14 to 28 AWG power cable
- Housing: Metal
- Weight: 370 g (0.82 lb)
- Operating temperature: -40 to 75°C (-40 to 167°F)
- Storage temperature (package included): -40 to 85°C (-40 to 185°F)
- Ambient relative humidity: 5 to 95% (non-condensing)
- Altitude: 2000 m
- Railway: EN 50121-4, EN 50155
- Safety: UL 508
- EMC: EN 55032/35, EN 61000-6-2/-6-4
- EMI: CISPR 32, FCC Part 15B Class A
- Shock: IEC 60068-2-27
- Vibration: IEC 60068-2-6
- MTBF: 1,341,777 hrs (Telcordia SR-332)

FAQs

Q: What input voltage does the ioPAC 8600-PW10-30W-T accept?
A: It accepts 24 to 110 VDC and provides two power inputs, allowing redundant power feeds.

Q: What is the operating temperature range?
A: The module operates from -40 to 75°C (-40 to 167°F), making it suitable for harsh industrial and railway environments.

Q: Which products is this power supply module designed for?
A: It is a power module for the Moxa ioPAC 8600 series of rugged modular programmable controllers.

Q: Is this module certified for railway applications?
A: Yes. It complies with EN 50155 and EN 50121-4 railway standards.

Q: How much power does it deliver?
A: The module is rated at 30 W.

Q: What type of power connector does it use?
A: It uses a spring-type Euroblock terminal that accepts 14 to 28 AWG power cable.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
