Moxa MDR-60-24 | MDR Series DIN-Rail Power Supply, 24 VDC, 60W, 2.5A

Moxa MDR-60-24 | MDR Series DIN-Rail Power Supply, 24 VDC, 60W, 2.5A

Authorised Moxa Partner

SKU:MDR-60-24

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Stock Status: Enquire

Description

The Moxa MDR-60-24 is a DIN-rail power supply delivering 24 VDC at 60W (2.5A), designed for industrial control cabinets and networking installations. It accepts a wide 85 to 264 VAC or 120 to 370 VDC input and includes inrush current protection, making it suitable for demanding industrial environments.

The output voltage can be adjusted from 24 to 30 VDC, and the unit operates across a -20 to 70°C temperature range, with full load supported up to 55°C. Its compact 40 x 90 x 100 mm footprint and 88% typical efficiency suit space-constrained enclosures powering industrial switches, gateways and I/O equipment.

Features

- High inrush current protection (30A at 115 VAC)
- Adjustable 24 to 30 VDC output range
- Wide 85 to 264 VAC and 120 to 370 VDC input range
- 20 to 70°C operating temperature range
- Constant current overload protection with automatic recovery
- 100% full load burn-in test
- UL/cUL listed, TUV/CB certified and CE marked
- Compact DIN-rail mounting design

Warranty

Moxa offers varying warranty periods depending on the product category:
• 5-Year Warranty: Applies to most industrial networking and connectivity products, including Ethernet switches, routers, wireless devices, serial converters, protocol gateways, and USB hubs.
• 3-Year Warranty: Covers x86-based industrial computers and panel PCs.
• 1-Year Warranty: Applies to external batteries, LCD panels, power adapters, antennas, and other select accessories.
Extended Warranty Options:
IP Trading offers tailored extended warranty solutions and support packages for Moxa products. Contact our team to explore options that align with your organization's needs.
https://www.moxa.com/en/support/repair-and-warranty/warranty-policy

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Output power: 60W
- Output voltage: 24 VDC, 0 to 2.5A
- Voltage adjustment range: 24 to 30 VDC
- Input voltage: 85 to 264 VAC (47 to 63 Hz) or 120 to 370 VDC
- Typical efficiency: 88%
- Ripple and noise: 150 mVp-p
- Hold-up time at full load: 20 ms at 115 VAC, 50 ms at 230 VAC
- Overload protection: 105 to 150% of rated output, constant current limiting with automatic recovery
- Operating temperature: -20 to 70°C (55°C maximum at full load)
- Ambient relative humidity: 20 to 90% (non-condensing)
- Dimensions: 40 x 90 x 100 mm
- Weight: 280 g
- Safety approvals: UL 508, EN 62368-1, IEC 62368-1

FAQs

Q: What output does the Moxa MDR-60-24 provide?
A: It provides 24 VDC at up to 2.5A, a total of 60W. The output voltage can be adjusted between 24 and 30 VDC.

Q: What input voltage range does it support?
A: It accepts 85 to 264 VAC (47 to 63 Hz) or 120 to 370 VDC, so it can be used on a wide range of AC and DC supplies.

Q: Can it operate in extreme temperatures?
A: Yes, the operating temperature range is -20 to 70°C. At full load the maximum ambient temperature is 55°C.

Q: How is it mounted?
A: It is a DIN-rail mounted unit with compact dimensions of 40 x 90 x 100 mm, intended for installation inside industrial control cabinets.

Q: What happens if the output is overloaded?
A: Overload protection activates at 105 to 150% of rated output power using constant current limiting, and the supply recovers automatically once the overload is removed.

Q: Which safety approvals does it hold?
A: It carries UL 508, EN 62368-1 and IEC 62368-1 safety approvals and is UL/cUL listed, TUV/CB certified and CE marked.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
