• White Fortinet FortiGate 900G rear with Ethernet ports and vents
1 1

Fortinet

Fortinet FG-900G-DC | Next-Gen Firewall, 4x 25G SFP28, Dual DC PSU

Fortinet FG-900G-DC | Next-Gen Firewall, 4x 25G SFP28, Dual DC PSU

Authorised Fortinet Partner

FG-900G-DC

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Fortinet FG-900G-DC is a 1RU enterprise next-generation firewall built for campus edge, large branch and data-centre edge deployments. This model features dual redundant, hot-swappable DC power supplies (48-60 VDC) and pairs 4x 25 GE SFP28 ultra-low-latency ports with SPU NP7 and CP9 hardware acceleration, delivering 164 Gbps firewall throughput and 22 Gbps NGFW throughput.

Connectivity includes 4x 10 GE SFP+ slots, 8x GE SFP slots, 16x GE RJ45 switch ports, a GE management port and a dedicated 2.5 GE/GE HA port. Two 480 GB onboard SSDs support local logging, a TPM provides secure key storage, and FortiOS delivers integrated security and SD-WAN with Active-Active, Active-Passive and clustering high availability.

Features

- Ultra-low-latency 25 GE SFP28 ports for latency-sensitive traffic
- NP7 network processor and CP9 content processor hardware acceleration
- Dual hot-swappable DC power supplies for power redundancy
- Runs FortiOS with integrated security and SD-WAN
- Onboard SSD storage for local logging
- TPM for secure key storage
- Active-Active, Active-Passive and clustering high availability

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 4x 25 GE SFP28 ultra-low-latency slots
- 4x 10 GE SFP+ slots
- 8x GE SFP slots
- 16x GE RJ45 switch ports plus 1x GE management port
- 1x 2.5 GE/GE HA port
- SPU NP7 and CP9 hardware acceleration
- Dual redundant hot-swappable DC power supplies, 48-60 VDC
- DC current maximum 7 A at 48 V
- IPv4 firewall throughput 164 / 163 / 153 Gbps (1518 / 512 / 64 byte UDP)
- IPS throughput 26 Gbps, NGFW throughput 22 Gbps, threat protection throughput 20 Gbps
- IPsec VPN throughput 55 Gbps (512 byte), SSL-VPN throughput 10 Gbps
- SSL inspection throughput 16.7 Gbps (IPS, average HTTPS)
- New sessions per second (TCP) 720,000, firewall policies 10,000
- Firewall latency 3.78 / 2.5 microseconds (64 byte UDP)
- 2x 480 GB onboard SSD storage
- Trusted Platform Module (TPM)
- 2x USB client, 2x USB server, 1x console port
- Includes 2x SFP SX transceivers
- Supports up to 96 FortiSwitches
- 1RU rack mount, 44.45 x 432 x 380 mm, 7.25 kg

FAQs

Q: What power input does the FG-900G-DC use?
A: This model uses dual redundant, hot-swappable DC power supplies rated for 48-60 VDC, with a maximum DC current of 7 A at 48 V.

Q: How does the FG-900G-DC differ from the AC model?
A: The hardware platform and interface layout are the same, but this SKU is fitted with dual DC power supplies (48-60 VDC) for DC-powered telecom and data-centre environments.

Q: What interfaces are available on the FG-900G-DC?
A: It provides 4x 25 GE SFP28, 4x 10 GE SFP+, 8x GE SFP, 16x GE RJ45 switch ports, 1x GE management port and 1x 2.5 GE/GE HA port.

Q: What throughput can the FG-900G-DC deliver?
A: It delivers up to 164 Gbps IPv4 firewall throughput, 26 Gbps IPS, 22 Gbps NGFW and 20 Gbps threat protection throughput.

Q: Does it support high availability?
A: Yes. It supports Active-Active, Active-Passive and clustering modes, with a dedicated 2.5 GE/GE HA port.

Q: Are transceivers included?
A: Two SFP SX transceivers are included. Additional SFP28 and SFP+ optics are sold separately.
