• White Fortinet FortiGate-60C back view with Ethernet and USB ports
1 1

Fortinet

Fortinet FG-200F-USG | Next-Gen Firewall, 18x GE RJ45, 8x SFP, 4x 10G SFP+, USG

Fortinet FG-200F-USG | Next-Gen Firewall, 18x GE RJ45, 8x SFP, 4x 10G SFP+, USG

Authorised Fortinet Partner

FG-200F-USG

Stock Status: Enquire

Request Quote
Sale Stock Status: Enquire
Shipping calculated at checkout.

Description

The Fortinet FortiGate 200F USG is a 1RU next-generation firewall and Secure SD-WAN appliance built for mid-sized to large enterprise campus and branch deployments. This US region (USG) hardware-only SKU provides 18x GE RJ45 ports (including dedicated MGMT and HA ports), 8x GE SFP slots and 4x 10GE SFP+ slots, with SoC4 and CP9 security processors accelerating threat protection. It delivers 27 Gbps firewall throughput, 5 Gbps IPS and 3.5 Gbps NGFW performance with no internal SSD.

The FortiGate 200F combines NGFW, Secure SD-WAN and secure web gateway functions in a single appliance, with TLS 1.3 deep inspection, scalable IPsec and SSL VPN, and integration with the Fortinet Security Fabric and FortiGuard services. It supports up to 64 FortiSwitches and 256 FortiAPs, with active-active and active-passive high availability for resilient network edge and campus core designs.

Features

- Next-generation firewall, Secure SD-WAN and secure web gateway in one appliance
- SoC4 and CP9 security processors for high threat-protection performance and low latency
- Deep application inspection with granular policy enforcement
- TLS 1.3 deep inspection of encrypted traffic
- Dynamic path selection and self-healing SD-WAN over any WAN transport
- Scalable IPsec VPN with automated hub-to-spoke and full-mesh tunnels
- Zero-touch provisioning and SD-WAN orchestration for centralised management
- Active-active, active-passive and clustering high availability
- Integration with the Fortinet Security Fabric and FortiGuard AI-powered services
- Redundant power supply support

Warranty

Fortinet provides robust warranty coverage for its hardware and software products, with durations and terms based on product category:
• Hardware Warranty: All Fortinet hardware products come with a 1-year (365 days) limited warranty from the Warranty Start Date, covering material defects in workmanship when compared to the published Functional Specifications.
• Software Warranty: Fortinet software is warranted for 90 days from the Warranty Start Date. An exception is FortiToken, which carries a 1-year warranty.
• Limited Lifetime Warranty Products:
Some products are covered by extended terms:
o FortiAP and FortiSwitch (excluding FortiSwitch-5000 series) include a limited lifetime warranty valid for 5 years beyond the product’s announced end-of-life date.
o FortiSwitch-5000 series is covered under the standard 1-year hardware warranty.
Extended Warranty Options:
IP Trading offers extended warranty solutions and ongoing FortiCare support services for Fortinet hardware. Contact our team to customise a support package that matches your operational needs.
https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 18x GE RJ45 ports (16 switch ports, 1 MGMT, 1 HA)
- 8x GE SFP slots
- 4x 10GE SFP+ slots (2 default FortiLink)
- Firewall throughput: 27 / 27 / 11 Gbps (1518 / 512 / 64 byte UDP)
- IPS throughput: 5 Gbps
- NGFW throughput: 3.5 Gbps
- Threat Protection throughput: 3 Gbps
- IPsec VPN throughput: 13 Gbps
- SSL-VPN throughput: 2 Gbps
- 3 million concurrent sessions, 280,000 new sessions per second
- Firewall latency: 4.78 μs (64 byte UDP)
- 10 virtual domains (default and maximum)
- Supports up to 64 FortiSwitches and 256 FortiAPs
- 1x USB port, 1x console port
- No internal storage
- 1 RU, 44 x 432 x 342 mm, 4.5 kg
- Power: 100-240V AC, 50-60 Hz, 101.92 W average, 118.90 W maximum
- Operating temperature: 0-40°C
- No transceivers included

FAQs

Q: Does the FG-200F-USG include an internal SSD?
A: No. The FG-200F-USG is a hardware-only model with no internal storage. Models with local SSD storage are sold under a different SKU.

Q: Are SFP or SFP+ transceivers included?
A: No. The appliance ships with no transceivers, so you will need to supply compatible SFP and SFP+ modules for the 8x GE SFP and 4x 10GE SFP+ slots.

Q: What does the USG suffix mean?
A: USG denotes the US region variant of the FortiGate 200F hardware.

Q: How many FortiSwitches and FortiAPs can it manage?
A: The FortiGate 200F can manage up to 64 FortiSwitches and up to 256 FortiAPs in total, 128 of them in tunnel mode.

Q: What high availability modes are supported?
A: It supports active-active, active-passive and clustering configurations, with a dedicated GE RJ45 HA port.

Q: What throughput can I expect with threat protection enabled?
A: The appliance is rated at 5 Gbps IPS, 3.5 Gbps NGFW and 3 Gbps Threat Protection throughput, with 27 Gbps for firewall-only traffic.
